面向电磁控制的SD6可编程驱动器

MC33816
正常供应

滚动图片以放大

恩智浦MC33816是一个可编程栅极驱动器IC，适用于精确的电磁控制应用。

  • 该IC包含5个外部MOSFET高边预驱动器和7个外部MOSFET低边预驱动器
  • 为MOSFET的栅极驱动提供了一个灵活的解决方案，实现了通用控制和最佳延迟时间
  • 栅极驱动、诊断和保护功能通过4个独立的微内核、两个代码RAM和两个数据RAM Bank来管理
  • 该IC包含两个内部稳压器

查看内部电路图

框图

MC33816系统

MC33816 System Diagram
获取框图PDF

特性

主要特性

  • 电池电压范围：5.0VBATT<32V
  • 预驱动器工作电压高达72V
  • 高边/低边预驱动PWM可高达100KHz(30n库伦)
  • 所有预驱动器都有4个可选的压摆率
  • 8个可选的预定义VDS监测阈值
  • 用于保护微代码的加密功能

购买/参数

2 结果

包含 0 不推荐用于新设计

部件

展开描述

订购

计算机辅助设计模型

状态

器件功能

End of Injection Detection

封装类型

封装端接数

预算报价（不含税）

Frequency (Max) (kHz)

通道数

保护

电源电压[最小]（V）

电源电压[最大]（V）

SPI [bits]

Number of High Side Pre Driver

Number Low Side Pre Driver

Ambient Operating Temperature (Min to Max) (℃)

MC33816AE
数据手册

正常供应

powertrain control, pre-driver

N

HLQFP64

64

1K @ CNY28.72

200

4

drain to source voltage/voltage source, open load, overcurrent, overtemperature, overvoltage protect, short-circuit, undervoltage, undervoltage lockout

5

72

16

5

7

-40 to 125

MC33816MAE
数据手册

正常供应

—

—

HLQFP64

64

1K @ CNY30.87

—

—

—

—

—

—

—

—

—

N true 0 PSPMC33816zh 10 勘误表 Errata t522 1 应用笔记 Application Note t789 3 应用笔记软件 Application Note Software t783 1 数据手册 Data Sheet t520 1 用户指南 User Guide t792 3 简介 Fact Sheet t523 1 zh 1 1 10.0 English The 33816 is a SMARTMOS programmable gate driver IC for precision solenoid control applications. 1353093661081728217618 PSP 4.4 MB None None documents None 1353093661081728217618 /docs/en/data-sheet/MC33816.pdf 4408774 /docs/en/data-sheet/MC33816.pdf MC33816 N N 2016-10-31 MC33816, SD6 programmable solenoid controller for precision solenoid control applications - Data Sheet /docs/en/data-sheet/MC33816.pdf /docs/en/data-sheet/MC33816.pdf Data Sheet N Y 980000996212993340 2023-08-18 pdf N en Feb 15, 2023 Data Sheet t520 数据手册 Data Sheet Y N MC33816, SD6 programmable solenoid controller for precision solenoid control applications - Data Sheet false zh zh 应用笔记 Application Note 3 2 5 English AN4849SW.zip /docs/en/application-note-software/AN4849SW.zip /docs/en/application-note-software/AN4849SW.zip Example of a four cylinder internal combustion engine (ICE) injector drive. 1389907360154740727519 PSP 369.9 KB Registration without Disclaimer None documents Extended 1389907360154740727519 /secured/assets/documents/en/application-note/AN4849.pdf 369909 /secured/assets/documents/en/application-note/AN4849.pdf AN4849 documents Y N 2016-10-31 AN4849, Four injector and fuel pump drive - Application Note /webapp/Download?colCode=AN4849&lang_cd=zh /secured/assets/documents/en/application-note/AN4849.pdf Application Note N 645036621402383989 2022-12-07 pdf Y en Jul 15, 2019 645036621402383989 Application Note Y N AN4849, Four injector and fuel pump drive - Application Note 3 3.0 English AN4954SW.zip /docs/en/application-note-software/AN4954SW.zip /docs/en/application-note-software/AN4954SW.zip This application note explains how to use MC33816 diagnostics in a typical four cylinder internal combustion engine (ICE) application. 1403195137764713068708 PSP 1.1 MB None None documents None 1403195137764713068708 /docs/en/application-note/AN4954.pdf 1109976 /docs/en/application-note/AN4954.pdf AN4954 documents N N 2014-06-19 AN4954, MC33816 Diagnostics - Application Note /docs/en/application-note/AN4954.pdf /docs/en/application-note/AN4954.pdf Application Note N 645036621402383989 2022-12-07 pdf N en Feb 3, 2016 645036621402383989 Application Note Y N AN4954, MC33816 Diagnostics - Application Note 4 1.0 English MC33816 and PT2000 are programmable solenoid controllers used to drive external N Channel MOSFETs, and are mainly used to drive direct fuel injectors and valves. 1444929321147694232840 PSP 323.0 KB None None documents None 1444929321147694232840 /docs/en/application-note/AN5203.pdf 323027 /docs/en/application-note/AN5203.pdf AN5203 documents N N 2015-10-15 AN5203, MC33816 vs. PT2000 - Application Note /docs/en/application-note/AN5203.pdf /docs/en/application-note/AN5203.pdf Application Note N 645036621402383989 2022-12-07 pdf N en Nov 18, 2015 645036621402383989 Application Note Y N AN5203, MC33816 vs. PT2000 - Application Note 用户指南 User Guide 3 5 2.0 English The PT2000 and MC33816 Developer Studio (IDE) software, and the KITPSCDEBUGEVM are used to configure, receive, and decode the trace codes coming from the device under test. 1447957687765700483033 PSP 3.2 MB None None documents None 1447957687765700483033 /docs/en/user-guide/KTPSCDEBUGUG.pdf 3155664 /docs/en/user-guide/KTPSCDEBUGUG.pdf KTPSCDEBUGUG documents N N 2015-11-19 KTPSCDEBUGUG, KITPSCDEBUG Evaluation Board - User&#8217;s Guide /docs/en/user-guide/KTPSCDEBUGUG.pdf /docs/en/user-guide/KTPSCDEBUGUG.pdf User Guide N 132339537837198660 2022-12-07 pdf N en Nov 16, 2015 132339537837198660 User Guide Y N KTPSCDEBUGUG, KITPSCDEBUG Evaluation Board - User&#8217;s Guide 6 2.0 English MC33816 Developer Studio is a Windows application created to streamline the development of micro code for the MC33816 Programmable Solenoid Controller. 1421361662470732669197 PSP 2.0 MB None None documents None 1421361662470732669197 /docs/en/user-guide/MC33816DSWUG.pdf 2020372 /docs/en/user-guide/MC33816DSWUG.pdf MC33816DSWUG documents N N 2015-01-15 MC33816DSWUG, MC33816 Developer Studio User&#8217;s Guide - User&#8217;s Guide /docs/en/user-guide/MC33816DSWUG.pdf /docs/en/user-guide/MC33816DSWUG.pdf User Guide N 132339537837198660 2023-06-18 pdf N en Oct 6, 2015 132339537837198660 User Guide Y N MC33816DSWUG, MC33816 Developer Studio User&#8217;s Guide - User&#8217;s Guide 7 1.0 English The PSC (Programmable Solenoid Controller) Simulator is an integrated design/simulation environment for the firmware required by a family of NXP Programmable Solenoid Controllers (PSC). In this chapter, the main functions of the PSC simulator are listed, along with a suggested development cycle. 1403904176274714861465 PSP 3.3 MB None None documents None 1403904176274714861465 /docs/en/user-guide/MC33816SIMUG.pdf 3315271 /docs/en/user-guide/MC33816SIMUG.pdf MC33816SIMUG documents N N 2014-06-27 MC33816SIMUG, MC33816 PSC Simulator - User&#8217;s Guide /docs/en/user-guide/MC33816SIMUG.pdf /docs/en/user-guide/MC33816SIMUG.pdf User Guide N 132339537837198660 2023-06-18 pdf N en Jun 27, 2014 132339537837198660 User Guide Y N MC33816SIMUG, MC33816 PSC Simulator - User&#8217;s Guide 应用笔记软件 Application Note Software 1 8 1.0 English Software example to drive four injectors managed in two banks, a single low pressure pump drive, and a variable frequency modulation (VFM) DC/DC converter. 1415311404196713676704 PSP 169.5 KB None None documents None 1415311404196713676704 /docs/en/application-note-software/AN4849SW.zip 169502 /docs/en/application-note-software/AN4849SW.zip AN4849SW documents N N 2019-10-02 AN4849SW, Software Files for AN4849 /docs/en/application-note-software/AN4849SW.zip /docs/en/application-note-software/AN4849SW.zip Application Note Software N 789425793691620447 2022-12-07 zip N en Oct 2, 2019 789425793691620447 Application Note Software Y N AN4849SW, Software Files for AN4849 勘误表 Errata 1 9 1.0 English This errata document applies to the MC33816 SMARTMOS<sup>&#174;</sup> product family. 1443219896420740470502 PSP 814.0 KB None None documents None 1443219896420740470502 /docs/en/errata/MC33816ER.pdf 813996 /docs/en/errata/MC33816ER.pdf MC33816ER documents N N 2015-09-25 MC33816ER, MC33816 Chip - Errata /docs/en/errata/MC33816ER.pdf /docs/en/errata/MC33816ER.pdf Errata N 155452329886410597 2022-12-07 pdf N en Oct 6, 2015 155452329886410597 Errata Y N MC33816ER, MC33816 Chip - Errata 简介 Fact Sheet 1 10 2 English NXP&#8217;s programmable gate driver for solenoid control integrates microcores, external MOSFET high-side pre-drivers, and external MOSFET low-side pre-drivers. 1467309667594711938150 PSP 309.6 KB None None documents None 1467309667594711938150 /docs/en/fact-sheet/PT2000A4FS.pdf 309593 /docs/en/fact-sheet/PT2000A4FS.pdf PT2000A4FS documents N N 2016-10-31 Solenoid Programmable Gate Driver ICs (PT2000, PT2001 and MC33816) - Fact Sheet /docs/en/fact-sheet/PT2000A4FS.pdf /docs/en/fact-sheet/PT2000A4FS.pdf Fact Sheet N 736675474163315314 2022-12-07 pdf N en Aug 28, 2019 736675474163315314 Fact Sheet Y N Solenoid Programmable Gate Driver ICs (PT2000, PT2001 and MC33816) - Fact Sheet false 0 MC33816 downloads zh-Hans true 1 Y PSP Y Y 勘误表 1 /docs/en/errata/MC33816ER.pdf 2015-09-25 1443219896420740470502 PSP 9 Oct 6, 2015 Errata This errata document applies to the MC33816 SMARTMOS<sup>&#174;</sup> product family. None /docs/en/errata/MC33816ER.pdf English documents 813996 None 155452329886410597 2022-12-07 N /docs/en/errata/MC33816ER.pdf MC33816ER, MC33816 Chip - Errata /docs/en/errata/MC33816ER.pdf documents 155452329886410597 Errata N en None Y pdf 1.0 N N MC33816ER, MC33816 Chip - Errata 814.0 KB MC33816ER N 1443219896420740470502 应用笔记 3 /secured/assets/documents/en/application-note/AN4849.pdf 2016-10-31 1389907360154740727519 PSP 2 Jul 15, 2019 Application Note Example of a four cylinder internal combustion engine (ICE) injector drive. Registration without Disclaimer /secured/assets/documents/en/application-note/AN4849.pdf English documents 369909 None 645036621402383989 2022-12-07 Y /webapp/Download?colCode=AN4849&lang_cd=zh AN4849, Four injector and fuel pump drive - Application Note /secured/assets/documents/en/application-note/AN4849.pdf documents 645036621402383989 Application Note N en Extended Y pdf 5 Y N AN4849, Four injector and fuel pump drive - Application Note 369.9 KB AN4849 N 1389907360154740727519 /docs/en/application-note/AN4954.pdf 2014-06-19 1403195137764713068708 PSP 3 Feb 3, 2016 Application Note This application note explains how to use MC33816 diagnostics in a typical four cylinder internal combustion engine (ICE) application. None /docs/en/application-note/AN4954.pdf English documents 1109976 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN4954.pdf AN4954, MC33816 Diagnostics - Application Note /docs/en/application-note/AN4954.pdf documents 645036621402383989 Application Note N en None Y pdf 3.0 N N AN4954, MC33816 Diagnostics - Application Note 1.1 MB AN4954 N 1403195137764713068708 /docs/en/application-note/AN5203.pdf 2015-10-15 1444929321147694232840 PSP 4 Nov 18, 2015 Application Note MC33816 and PT2000 are programmable solenoid controllers used to drive external N Channel MOSFETs, and are mainly used to drive direct fuel injectors and valves. None /docs/en/application-note/AN5203.pdf English documents 323027 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN5203.pdf AN5203, MC33816 vs. PT2000 - Application Note /docs/en/application-note/AN5203.pdf documents 645036621402383989 Application Note N en None Y pdf 1.0 N N AN5203, MC33816 vs. PT2000 - Application Note 323.0 KB AN5203 N 1444929321147694232840 应用笔记软件 1 /docs/en/application-note-software/AN4849SW.zip 2019-10-02 1415311404196713676704 PSP 8 Oct 2, 2019 Application Note Software Software example to drive four injectors managed in two banks, a single low pressure pump drive, and a variable frequency modulation (VFM) DC/DC converter. None /docs/en/application-note-software/AN4849SW.zip English documents 169502 None 789425793691620447 2022-12-07 N /docs/en/application-note-software/AN4849SW.zip AN4849SW, Software Files for AN4849 /docs/en/application-note-software/AN4849SW.zip documents 789425793691620447 Application Note Software N en None Y zip 1.0 N N AN4849SW, Software Files for AN4849 169.5 KB AN4849SW N 1415311404196713676704 数据手册 1 /docs/en/data-sheet/MC33816.pdf 2016-10-31 1353093661081728217618 PSP 1 Feb 15, 2023 Data Sheet 数据手册 The 33816 is a SMARTMOS programmable gate driver IC for precision solenoid control applications. None /docs/en/data-sheet/MC33816.pdf English 4408774 None Data Sheet 2023-08-18 N /docs/en/data-sheet/MC33816.pdf MC33816, SD6 programmable solenoid controller for precision solenoid control applications - Data Sheet /docs/en/data-sheet/MC33816.pdf documents 980000996212993340 Data Sheet N Y en None Y t520 pdf 10.0 N N MC33816, SD6 programmable solenoid controller for precision solenoid control applications - Data Sheet 4.4 MB MC33816 N 1353093661081728217618 用户指南 3 /docs/en/user-guide/KTPSCDEBUGUG.pdf 2015-11-19 1447957687765700483033 PSP 5 Nov 16, 2015 User Guide The PT2000 and MC33816 Developer Studio (IDE) software, and the KITPSCDEBUGEVM are used to configure, receive, and decode the trace codes coming from the device under test. None /docs/en/user-guide/KTPSCDEBUGUG.pdf English documents 3155664 None 132339537837198660 2022-12-07 N /docs/en/user-guide/KTPSCDEBUGUG.pdf KTPSCDEBUGUG, KITPSCDEBUG Evaluation Board - User&#8217;s Guide /docs/en/user-guide/KTPSCDEBUGUG.pdf documents 132339537837198660 User Guide N en None Y pdf 2.0 N N KTPSCDEBUGUG, KITPSCDEBUG Evaluation Board - User&#8217;s Guide 3.2 MB KTPSCDEBUGUG N 1447957687765700483033 /docs/en/user-guide/MC33816DSWUG.pdf 2015-01-15 1421361662470732669197 PSP 6 Oct 6, 2015 User Guide MC33816 Developer Studio is a Windows application created to streamline the development of micro code for the MC33816 Programmable Solenoid Controller. None /docs/en/user-guide/MC33816DSWUG.pdf English documents 2020372 None 132339537837198660 2023-06-18 N /docs/en/user-guide/MC33816DSWUG.pdf MC33816DSWUG, MC33816 Developer Studio User&#8217;s Guide - User&#8217;s Guide /docs/en/user-guide/MC33816DSWUG.pdf documents 132339537837198660 User Guide N en None Y pdf 2.0 N N MC33816DSWUG, MC33816 Developer Studio User&#8217;s Guide - User&#8217;s Guide 2.0 MB MC33816DSWUG N 1421361662470732669197 /docs/en/user-guide/MC33816SIMUG.pdf 2014-06-27 1403904176274714861465 PSP 7 Jun 27, 2014 User Guide The PSC (Programmable Solenoid Controller) Simulator is an integrated design/simulation environment for the firmware required by a family of NXP Programmable Solenoid Controllers (PSC). In this chapter, the main functions of the PSC simulator are listed, along with a suggested development cycle. None /docs/en/user-guide/MC33816SIMUG.pdf English documents 3315271 None 132339537837198660 2023-06-18 N /docs/en/user-guide/MC33816SIMUG.pdf MC33816SIMUG, MC33816 PSC Simulator - User&#8217;s Guide /docs/en/user-guide/MC33816SIMUG.pdf documents 132339537837198660 User Guide N en None Y pdf 1.0 N N MC33816SIMUG, MC33816 PSC Simulator - User&#8217;s Guide 3.3 MB MC33816SIMUG N 1403904176274714861465 简介 1 /docs/en/fact-sheet/PT2000A4FS.pdf 2016-10-31 1467309667594711938150 PSP 10 Aug 28, 2019 Fact Sheet NXP&#8217;s programmable gate driver for solenoid control integrates microcores, external MOSFET high-side pre-drivers, and external MOSFET low-side pre-drivers. None /docs/en/fact-sheet/PT2000A4FS.pdf English documents 309593 None 736675474163315314 2022-12-07 N /docs/en/fact-sheet/PT2000A4FS.pdf Solenoid Programmable Gate Driver ICs (PT2000, PT2001 and MC33816) - Fact Sheet /docs/en/fact-sheet/PT2000A4FS.pdf documents 736675474163315314 Fact Sheet N en None Y pdf 2 N N Solenoid Programmable Gate Driver ICs (PT2000, PT2001 and MC33816) - Fact Sheet 309.6 KB PT2000A4FS N 1467309667594711938150 true Y Products
