8位通用MP MCU

S08MP
正常供应

S08MP16是一款低成本8位MCU，为各种工业和汽车应用提供安全、精确和经济的电机控制。作为无刷直流(BLDC)电机应用的理想的入门级解决方案，它具有一个8通道脉宽调制器(PWM)/flextimer模块，提供硬件死区时间插入、模拟比较器、可编程增益放大器和一个带PWM硬件触发功能的12位模数转换器(ADC)。S08MP16还配有独立时钟源的COP和循环冗余校验(CRC)引擎，可为执行IEC60730标准的、有较高安全要求的应用提供时钟故障防护和存储器内容校验功能。

产品详情

框图

Freescale S08MP Microcontroller Block Diagram

Freescale S08MP Microcontroller Block Diagram
获取框图PDF

特征

S08中央处理单元(CPU)

  • 2.7–5.5V条件下HCS08 CPU频率高达50 MHz，温度范围为-40°C至+105°C
  • 附加了后台指令(BGND)的HCS08指令集

片上存储器

  • 高达可达16K闪存，在整个工作电压和温度范围内均可进行读取/编程/擦除操作
  • 高达1 KB RAM
  • 安全电路可防止对RAM和闪存内容的非法访问

节电模式

  • 两种低功耗停止模式以及低功耗等待模式
  • 时钟门控寄存器可关闭闲置模块的时钟

外设

  • 模数转换器(ADC)
    • 13个通道
    • 12位分辨率
    • 2.5 µs转换时间
    • 自动比较功能
    • 1.7 mV/°C温度传感器
    • 内部带隙参考通道
    • 在停止3模式运行
  • 1个2通道FlexTimer + 1个6通道
    • 支持高达51.34 MHz的运行
    • 可选择捕捉输入
    • 输出比较
    • 边沿或中心对齐的PWM
    • 死区时间插入
    • 故障输入
  • MTIM: 简单的8位定时器，有4个可通过软件选择的时钟源和一个可编程中断
  • 3个高速模拟比较器(HSACMP)
    • +ve和-ve输入
    • 可分别选择在比较器输出的上升沿和下降沿产生中断
    • 过滤
    • 窗口设置
    • 可选择将HSCMP1和HSCMP2输出发送到FTM1模块
    • 在停止3模式运行
  • 可编程增益放大器(PGA)
    • 差分可编程增益放大器，增益可设置为(x1, x2, x4, x8, x16 或x32)
  • 2个可编程延时模块(PDB)
    • PDB1将PWM与ADC采样同步
    • PDB2将PWM与模拟比较器的比较窗口同步
  • 独立时钟源的COP和循环冗余校验生成器

开发支持

  • 单线后台调试接口
  • 断点功能
  • ICE调试模块
    • 3个比较器和9种触发模式
    • 8个深度FIFO用于存储流程更改地址和纯事件数据
    • 支持标记和强制断点

产品长期供货计划
