Kinetis® KW30Z-2.4 GHz Bluetooth Low Energy (BLE 4.1)微控制器，基于Arm® Cortex®-M0+内核

KW30Z
不推荐用于新设计

KW30Z是一款超低功耗、高集成度的单芯片器件系列，让便携式、超低功耗的嵌入式系统具备Bluetooth® Smart/Bluetooth® Low Energy (BLE) v4.1射频连接。应用包括便携式医疗设备、可穿戴的运动和健身设备、AV遥控器、电脑键盘和鼠标、游戏控制器和门禁。

KW30Z无线MCU集成了一个2.4 GHz收发器，一个ARM® Cortex®-M0+ CPU，160 KB闪存和20 KB SRAM，BLE链路层硬件，硬件安全和外围设备，可满足目标应用的需求。

框图

Kinetis W Series KW30Z MCUs Block Diagram

Kinetis<sup>&#174;</sup> W Series KW30Z MCUs Block Diagram
获取框图PDF

特征

Bluetooth Low Energy无线电功能

  • 兼容2.4 GHz Bluetooth Low Energy V4.1
  • 典型的接收灵敏度 = -91 dBm
  • 可编程的发射器输出功率高达+3.5 dBm

内核和存储器

  • 高达48 MHz Arm® Cortex®-M0+内核
  • 片上160 KB闪存
  • 片上20 KB SRAM

功耗低，工作电压范围

  • 9个低功耗模式，根据应用需求提供优化的电源
  • 典型接收/发射电流(直流/支持直流)： 6.5 mA / 8.4 mA
  • 旁路电压：1.71V至3.6V
  • DCDC转换器降压配置：2.1V至4.2V
  • DCDC转换器升压配置：0.9V 至1.795V

模拟模块

  • 16位模数转换器(ADC)
  • 12位数模转换器 (DAC)
  • 6位高速模拟比较器(CMP)

安全性

  • AES-128加速器(AESA)，真随机数发生器(TRNG)

支持软件

  • BLE主机协议栈和资料
  • Kinetis®软件开发套件(SDK)
  • 多款实时操作系统，包括MQX和FreeRTOS

对比表

Kinetis KW40Z系列推荐解决方案

部件编号 无线连接协议 封装大小 硬件开发工具
MKW40Z160VHT4 Bluetooth Low Energy和IEEE 802.15.4 7 mm x 7 mm x 1 mm 48引脚层压QFN封装


FRDM-KW40Z
USB-KW40Z
MKW30Z160VHM4 Bluetooth Low Energy协议 5 mm x 5 mm x 1 mm 32引脚层压QFN封装
MKW20Z160VHT4 IEEE 802.15.4 7 mm x 7 mm x 1 mm 48引脚层压QFN封装
