GD3160半桥评估套件

FRDMGD3160XM3EVM
正常供应

滚动图片以放大

FRDMGD3160XM3EVM是一款半桥评估套件，安装了两个MC33GD3160单通道IGBT栅极驱动设备。该套件包含Freedom KL25Z微控制器硬件，用于连接安装有Flex GUI软件的PC，可采用菊花链或独立配置的方式与MC33GD3160栅极驱动器上的SPI寄存器进行通信。KITGD3160TREVB转换板用于将MCU和MC33GD3160栅极驱动器之间的3.3 V信号转换为5.0 V信号。评估套件可以连接到Wolfspeed XM3 SiC MOSFET模块，以进行半桥评估和应用开发。

支持的器件

电源管理

动力和发动机控制

  • GD3160: 面向SiC MOSFET的具有段式驱动的先进高压隔离栅极驱动器

特征

Features

  • Compatible with XM3 SiC MOSFET module
  • Flex GUI Graphical User Interface available for use with kit
  • Daisy chain SPI interface configurability
  • Easy to configure jumper options
  • SPI configurable register options using Flex GUI
  • Double Pulse and Short Circuit evauations
  • Fiber Optic connections for external PWM inputs

购买选项

FRDMGD3160XM3EVM-Image

点击展开

  • FRDMGD3160XM3EVM
    正常供应

  • GD3160 XM3 Half-Bridge Evaluation Kit.

  • 套件包含

    该半桥评估套件具有面向IGBT/SiC MOSFET的GD3160栅极驱动设备

    • 配备KL25Z MCU的KITGD3160TREVB转换板
    • Micro USB线缆
    • 快速入门指南
  • $194.03 USD
  • 数量为 1
    • 供货情况: 现货
    • 库存: 5
    • 配送: 正常情况下 1-2个工作日内发货
加入购物车
从分销商处购买
