电动汽车(EV)牵引逆变器

Dual Traction Inverter Demo

点击播放视频

恩智浦电动汽车牵引逆变器是电动汽车的关键部件，负责将电池的直流电转换为交流电来驱动牵引电机。它必须能够提供高功率（从80千瓦到超过200千瓦），耐高温且重量轻。

恩智浦的电动汽车牵引逆变器系统解决方案具有多核锁步MCU、安全SBC、CAN、以太网PHY和高压栅极驱动器，可高效可靠地控制牵引电机的电源转换。

恩智浦的系统解决方案提供了一套丰富的电机控制软件包，可配合优化的硬件。电动汽车牵引逆变器系统还提供对大功率开关的精确控制、监测和保护，以提高能效和可靠性。该系统提供准确和高效的电机速度和扭矩控制，并符合ISO26262标准的ASIL D合规要求。

为了支持客户的牵引逆变器开发并缩短上市时间，恩智浦提供了一个易于使用的电动汽车功率逆变器控制参考平台和系统使能软件。这些设计平台还包括用于IGBT或SiC MOSFET模块的原理图、BoM、布局文件和安全文档。

应用详情

框图

牵引逆变器

产品推荐:

牵引逆变器

选择区块查看产品推荐.

  • FS26: 功能安全系统基础芯片，低功耗，面向ASIL D系统
  • FS6500: 符合1级和0级安全标准的电源系统基础芯片，带有CAN灵活数据收发器
  • TJA1462: 具有待机模式的CAN信号质量提升(SIC)收发器
  • TJA1152: 具有待机模式的安全HS-CAN收发器
  • TJA1044: High-Speed CAN Transceiver with Standby Mode - Mantis Family
  • S32K39-37-36: 面向电气化应用的S32K39/37/36微控制器
  • GD3162: 具有动态栅极强度控制的先进高压隔离栅极驱动器
  • GD3160: 面向SiC MOSFET的具有段式驱动的先进高压隔离栅极驱动器
  • GD3100: 面向IGBT和SiC MOSFET的高级高压隔离栅极驱动器
  • TJA1103: TJA1103，符合ASIL B安全标准的汽车以太网100BASE-T1 PHY收发器
  • TJA1101: TJA1101B，符合IEEE 100BASE-T1标准的汽车以太网PHY收发器
  • P3T1755DP: I3C/I²C总线精确数字温度传感器，精度为±0.5 °C
  • P3T1750DP: I3C/I2C总线、精度为±1°C的数字温度传感器
获取框图PDF
