SLRC610: High-Performance Frontend for ICODE® Products
Not recommended for new designs. For new designs, please use recommended product SLRC610\n plus from the CLRC663 plus family.
Please check the new online NFC Antenna Tool for tag and reader devices.
The SLRC610 is a high-performance yet low-cost RFID frontend supporting vicinity protocols according to ISO/IEC15693, EPC UID and ISO/IEC 18000-3 mode 3/ EPC Class-1 HF. The LRC610 supports the connection of a secure access module (SAM), where a dedicated separate I2C interface is implemented for. The SAM can be used for highly secure key storage and acts as a very performant crypto coprocessor. A dedicated SAM is available to connect the SLRC610.
SLRC610
产品详情
Features
Key Benefits
- High-performance multi-protocol NFC frontend
- Supporting vicinity protocols
- Separate I²C bus interface for connection of a secure access module (SAM)
- Flexible and efficient power saving modes
- 3 to 5.5 V power supply
RF standard compliance
- ISO/IEC 15693 (ICODE SLIX family ICODE DNA) and ISO/IEC 18000-3 mode 3 (ICODE ILT family)
Host interfaces
- SPI
- I²C bus
- RS232 Serial UART
