Flexis™ 32位ColdFire®. V1微控制器

MCF51JE
正常供应
Introducing Five New Microcontrollers (MCUs) for Medical Solutions

点击播放视频

MCF51JE256/128 (JE256/128)在一个32位微控制器中实现了超低功耗运行、USB连接和较高的测量精度，使设计者可以开发出功能更齐全、性价比更高的系统。JE256/128集成了高分辨率的模数转换器(ADC)和数模转换器(DAC)模块，配备丰富的外设组合，包括USB 2.0主机/设备/OTG控制器、多个串行接口以及1个外部总线接口。

JE256/128是我们Flexis® MCU系列的成员，包括8位S08和32位V1 ColdFire® MCU，这两者具有通用的外设组合和开发工具，为迁移提供了极大的灵活性。恩智浦提供一套全面的开发工具和软件，帮助设计者进行快速、轻松的设计。

框图

ColdFire MCF51JE微控制器框图

ColdFire MCF51JE Microcontroller Block Diagram
获取框图PDF

特性

  • 片上存储器
    • 高达256 KB闪存
    • 高达32 KB SRAM
    • Mini FlexBus （外部总线接口）
  • 测量引擎单元
    • 12位SAR ADC - 高分辨率ADC
    • 可编程延迟模块
    • PRACMP - 带5位DAC的模拟比较器
    • 内部参考电压
  • 通信外设
    • 多达69个通用输入/输出(GPIO)
    • USB器件/主器件/OTG控制器
    • 两个串行外设接口(SPI)
    • 两个串行通信接口(SCI)
    • I²C
  • 定时器
    • 两个4通道定时器
    • 脉宽调制器
    • 钟表时间模块
    • 载波调制定时器
  • 系统集成
    • 两个键盘中断(KBI)
    • 低压指示器
    • 低功耗停止模式2电流：500 nA （32 KB的有效SRAM）
  • 本产品包含在恩智浦产品长期供货计划中，自推出后至少保证15年供货。

购买/参数

5 结果

包含 0 不推荐用于新设计

部件

展开描述

订购

计算机辅助设计模型

状态

封装端接数

封装类型

预算报价（不含税）

运行频率[最高]（MHz）

Flash (kB)

RAM (kB)

GPIO

电源电压[最小]（V）

电源电压[最大]（V）

Ambient Operating Temperature (Min to Max) (℃)

MCF51JE128CLK
数据手册

正常供应

80

LQFP80

10K @ CNY41.50

50

128

32

47

1.8

3.6

-40 to 85

MCF51JE256CLK
数据手册

正常供应

80

LQFP80

10K @ CNY44.95

50

256

32

47

1.8

3.6

-40 to 85

MCF51JE256CLL
数据手册

正常供应

100

LQFP100

10K @ CNY46.10

50

256

32

65

1.8

3.6

-40 to 85

MCF51JE256VLK
数据手册

正常供应

80

LQFP80

10K @ CNY47.24

50

256

32

47

1.8

3.6

-40 to 105

MCF51JE256VLL
数据手册

正常供应

100

LQFP100

10K @ CNY48.39

50

256

32

65

1.8

3.6

-40 to 105

N true 0 PSPMCF51JEzh 17 产品变更通知 Product Change Notice t526 1 参考手册 Reference Manual t877 2 应用笔记 Application Note t789 9 应用笔记软件 Application Note Software t783 2 数据手册 Data Sheet t520 1 用户指南 User Guide t792 1 简介 Fact Sheet t523 1 zh 3 1 2 English MCF51JE256FS: The MCF51JE256/128 (JE256/128) provides ultra-low-power operation, USB connectivity and high measurement accuracy, all in a single 32-bit microcontroller, allowing designers to develop a more fully featured system at a lower cost. The JE256/128 integrates high-resolution ADC and DAC modules and a rich peripheral set including a USB 2.0 host/device/OTG controller, multiple serial interfaces and an external bus interface. 1271941518919716674641 PSP 268.6 KB None None documents None 1271941518919716674641 /docs/en/fact-sheet/MCF51JE256FS.pdf 268618 /docs/en/fact-sheet/MCF51JE256FS.pdf MCF51JE256FS N N 2020-02-18 MCF51JE256/128 Ultra-low-power MCU with USB connectivity - Fact Sheet /docs/en/fact-sheet/MCF51JE256FS.pdf /docs/en/fact-sheet/MCF51JE256FS.pdf Fact Sheet N Y 736675474163315314 2022-12-07 pdf N en Feb 18, 2020 Fact Sheet t523 简介 Fact Sheet Y N MCF51JE256/128 Ultra-low-power MCU with USB connectivity - Fact Sheet 2 4 English The MCF51JE256 series devices are members of the low-cost, low-power, high-performance ColdFire &#174; V1 family of 32-bit microcontrollers (MCUs). This MCF51JE256 has the following features: Up to 50.33 MHz ColdFire CPU, 256 K Flash, 32 KB System Random-access memory (RAM), 80 LQFP, 81 BGA. 1272665028703711826856 PSP 657.9 KB None None documents None 1272665028703711826856 /docs/en/data-sheet/MCF51JE256.pdf 657930 /docs/en/data-sheet/MCF51JE256.pdf MCF51JE256 N N 2010-04-30 MCF51JE256/128 - Data Sheet /docs/en/data-sheet/MCF51JE256.pdf /docs/en/data-sheet/MCF51JE256.pdf Data Sheet N Y 980000996212993340 2022-12-07 pdf N en Aug 13, 2012 Data Sheet t520 数据手册 Data Sheet Y N MCF51JE256/128 - Data Sheet 3 2 English The primary objective of this reference manual is to define the processor for software and hardware developers. The MCF51JE256 and MCF51JE128 series microcontrollers are systems-on-chip (SoCs) that are based on the ColdFire &#174; V1 core and: Operate at processor core speeds up to 50.33 MHz (peripherals operate at half of this speed) and integrate technologies that are important for today&#8217;s consumer and industrial applications, such as USB On-the-Go. 1291248438461720562504 PSP 4.9 MB None None documents None 1291248438461720562504 /docs/en/reference-manual/MCF51JE256RM.pdf 4946036 /docs/en/reference-manual/MCF51JE256RM.pdf MCF51JE256RM N 2010-12-01 MCF51JE256 - Reference Manual /docs/en/reference-manual/MCF51JE256RM.pdf /docs/en/reference-manual/MCF51JE256RM.pdf Reference Manual N Y 500633505221135046 2022-12-07 pdf en Dec 1, 2010 Reference Manual t877 参考手册 Reference Manual Y N MCF51JE256 - Reference Manual false zh zh 参考手册 Reference Manual 1 4 3 English This manual contains detailed information about the instruction set architecture (ISA) for all versions of ColdFire &#174; microprocessors. Within the ColdFire Family, each generation of hardware microarchitecture is known as a Version, beginning with the original Version 2 (V2) core implementation, the first native ColdFire processor implementation. The original ColdFire ISA was developed from a reduced version of the M68000 instruction set that was targeted to hit a &#8220;sweet-spot&#8221;. C996188491014 PSP 1.7 MB None None documents None C996188491014 /docs/en/reference-manual/CFPRM.pdf 1706629 /docs/en/reference-manual/CFPRM.pdf CFPRM documents N 2001-07-26 ColdFire<sup>&#174;</sup> &#174; Family Programmer&#8217;s - Reference Manual /docs/en/reference-manual/CFPRM.pdf /docs/en/reference-manual/CFPRM.pdf Reference Manual N 500633505221135046 2022-12-07 pdf en Mar 8, 2005 500633505221135046 Reference Manual Y N ColdFire<sup>&#174;</sup> &#174; Family Programmer&#8217;s - Reference Manual 应用笔记 Application Note 9 5 0 English This Application Note discusses important considerations and guidelines for implementing in-software flash programming on Kinetis and ColdFire+ MCUs 1366267658721722833617 PSP 260.0 KB None None documents None 1366267658721722833617 /docs/en/application-note/AN4695.pdf 260008 /docs/en/application-note/AN4695.pdf AN4695 documents N N 2016-10-31 Implementing in-software flash programming on Kinetis MCUs /docs/en/application-note/AN4695.pdf /docs/en/application-note/AN4695.pdf Application Note N 645036621402383989 2022-12-07 pdf N en Apr 17, 2013 645036621402383989 Application Note N Implementing in-software flash programming on Kinetis MCUs 6 0 English ANQRUGSW.zip /docs/en/application-note-software/ANQRUGSW.zip /docs/en/application-note-software/ANQRUGSW.zip The Flexis&#8482; MM and JE series provides all the&#13;&#10;integrated analog peripherals that is needed to make user application perform as a breakthrough medical design.&#13;&#10;Integrated 16-bit ADC, 12-bit DAC, op-amps,&#13;&#10;Transimpedance amplifiers and USB connectivity make the Flexis&#8482; MM and JE ideal for medical applications.&#13;&#10;This document is intended to provide a quick reference to start using the analog peripherals in the Flexis&#8482; MM and JE series. The document provides a 1272074387577746295880 PSP 2.6 MB None None documents None 1272074387577746295880 /docs/en/application-note/ANPERIPHQRUG.pdf 2563318 /docs/en/application-note/ANPERIPHQRUG.pdf ANPERIPHQRUG documents N 2010-04-23 Quick Reference User Guide for Analog Peripherals on the MM and JE Family /docs/en/application-note/ANPERIPHQRUG.pdf /docs/en/application-note/ANPERIPHQRUG.pdf Application Note N 645036621402383989 2022-12-07 pdf en Jul 15, 2010 645036621402383989 Application Note Y N Quick Reference User Guide for Analog Peripherals on the MM and JE Family 7 0 English AN3412SW.zip /docs/en/application-note-software/AN3412SW.zip /docs/en/application-note-software/AN3412SW.zip This application note explains how the twisted nematic (TN) liquid crystal displays (LCDs) work and how these kinds of LCDs can be controlled using the GPIO pins of a microcontroller. There are two ways to control the TN LCDs, statically and dynamically. The driver discussed in this document is intended to drive dynamic LCDs. The dynamically driven LCDs require a pure AC voltage waveform applied to the electrodes of the LCD. Each electrode needs one backplane electrode and one frontplane terminal to be disp 1272075138770713976182 PSP 5.5 MB None None documents None 1272075138770713976182 /docs/en/application-note/AN3412.pdf 5477882 /docs/en/application-note/AN3412.pdf AN3412 documents N 2010-04-23 Dynamic LCD Driver Using GPIO Pins /docs/en/application-note/AN3412.pdf /docs/en/application-note/AN3412.pdf Application Note N 645036621402383989 2022-12-07 pdf en Apr 26, 2010 645036621402383989 Application Note Y N Dynamic LCD Driver Using GPIO Pins 8 0 English This Application Note describes how to use Tower<sup>&#174;</sup> TWR-LCD board to display eGUI or other graphic user interfaces such as microWindows with Kinetis MCUs 1326899406187705806071 PSP 1.7 MB None None documents None 1326899406187705806071 /docs/en/application-note/AN4452.pdf 1718385 /docs/en/application-note/AN4452.pdf AN4452 documents N N 2016-10-31 Display eGUI using TWR-LCD board /docs/en/application-note/AN4452.pdf /docs/en/application-note/AN4452.pdf Application Note N 645036621402383989 2022-12-07 en Jan 17, 2012 645036621402383989 Application Note Y N Display eGUI using TWR-LCD board 0 Chinese 1326899406187705806071zh PSP 1.7 MB None None documents None 1326899406187705806071 /docs/zh/application-note/AN4452.pdf 1718385 /docs/zh/application-note/AN4452.pdf AN4452 documents N N 2016-10-31 Display eGUI using TWR-LCD board /docs/zh/application-note/AN4452.pdf /docs/zh/application-note/AN4452.pdf Application Note N 645036621402383989 2022-12-07 pdf N zh 645036621402383989 Application Note N 采用TWR-LCD电路板显示eGUI 9 0 English AN4116SW.zip /docs/en/application-note-software/AN4116SW.zip /docs/en/application-note-software/AN4116SW.zip This application note shows how to easily migrate the communication protocol C12.18 which is already implemented on the MCF51EM256 on to new devices.This is explained in the NXP application note titled Using the MCF51EM Family for Infrared Communication (document AN3938). 1272071979959717585300 PSP 796.4 KB None None documents None 1272071979959717585300 /docs/en/application-note/AN4116.pdf 796412 /docs/en/application-note/AN4116.pdf AN4116 documents N 2010-04-23 Using the MM/JE Flexis<sup>&#174;</sup> Families for Infrared Communication /docs/en/application-note/AN4116.pdf /docs/en/application-note/AN4116.pdf Application Note N 645036621402383989 2022-12-07 pdf en Jul 30, 2010 645036621402383989 Application Note Y N Using the MM/JE Flexis<sup>&#174;</sup> Families for Infrared Communication 10 0 English Explaining how to add the FreeMASTER serial driver software to the embedded application and configure it. The FreeMASTER serial driver is a piece of code that enables an embedded application to communicate with the FreeMASTER PC application. 1370013855832696188368 PSP 2.2 MB Registration without Disclaimer None documents Extended 1370013855832696188368 /secured/assets/documents/en/application-note/AN4752.pdf 2220944 /secured/assets/documents/en/application-note/AN4752.pdf AN4752 documents Y N 2016-10-31 AN4752: FreeMASTER Usage, Serial Driver Implementation – Application Note /webapp/Download?colCode=AN4752&lang_cd=zh /secured/assets/documents/en/application-note/AN4752.pdf Application Note N 645036621402383989 2024-07-15 pdf Y en May 31, 2013 645036621402383989 Application Note Y N AN4752: FreeMASTER Usage, Serial Driver Implementation – Application Note 11 0 English AN4115SW.zip /docs/en/application-note-software/AN4115SW.zip /docs/en/application-note-software/AN4115SW.zip AN4115: This application note discusses a physical layer driver used to establish IrDA communication on NXP devices in the MM/JE Flexis<sup>&#174;</sup> families, using the Carrier Modulator Timer (CMT) as transmitter and a Timer/Pulse-Width Modulator (TPM) as receptor. It also explains a driver to handle a Secure Digital (SD) card through a Serial Peripheral Interface (SPI) module. 1272070234970717037114 PSP 445.8 KB None None documents None 1272070234970717037114 /docs/en/application-note/AN4115.pdf 445848 /docs/en/application-note/AN4115.pdf AN4115 documents N 2010-04-23 AN4115, IrDA Driver and SD Card File System on MM/JE Flexis<sup>&#174;</sup> Families - Application Notes /docs/en/application-note/AN4115.pdf /docs/en/application-note/AN4115.pdf Application Note N 645036621402383989 2022-12-07 pdf en Jul 30, 2010 645036621402383989 Application Note Y N AN4115, IrDA Driver and SD Card File System on MM/JE Flexis<sup>&#174;</sup> Families - Application Notes 12 0 English This Application Note shows an implementation of a mass storage device (MSD) USB bootloader for Kinetis K, L and W Series MCUs, MCF51JM and MCF522xx 1318880133881734730624 PSP 511.8 KB None None documents None 1318880133881734730624 /docs/en/application-note/AN4379.pdf 511834 /docs/en/application-note/AN4379.pdf AN4379 documents N N 2016-10-31 USB Mass Storage Device (MSD) Bootloader /docs/en/application-note/AN4379.pdf /docs/en/application-note/AN4379.pdf Application Note N 645036621402383989 2022-12-07 en Oct 17, 2011 645036621402383989 Application Note Y N USB Mass Storage Device (MSD) Bootloader 0 Chinese 1318880133881734730624zh PSP 511.8 KB None None documents None 1318880133881734730624 /docs/zh/application-note/AN4379.pdf 511834 /docs/zh/application-note/AN4379.pdf AN4379 documents N N 2016-10-31 USB Mass Storage Device (MSD) Bootloader /docs/zh/application-note/AN4379.pdf /docs/zh/application-note/AN4379.pdf Application Note N 645036621402383989 2022-12-07 pdf N zh 645036621402383989 Application Note N USB大容量存储设备(MSD)引导加载程序 13 0 English Presenting the use of the Rational ClearCase version control system in CodeWarrior 10.3. It lists the files needed to maintain the project and describes how to install, set up, use, and uninstall the ClearCase plugin in CodeWarrior 10.3. The ClearCase plugin enables you to check files in and out directly from within CodeWarrior, making the work more effective. 1369937932059742568603 PSP 477.3 KB None None documents None 1369937932059742568603 /docs/en/application-note/AN4753.pdf 477314 /docs/en/application-note/AN4753.pdf AN4753 documents N N 2016-10-31 AN4753: Rational ClearCase Use in CodeWarrior 10.3 – Application Note /docs/en/application-note/AN4753.pdf /docs/en/application-note/AN4753.pdf Application Note N 645036621402383989 2024-07-15 pdf N en May 30, 2013 645036621402383989 Application Note Y N AN4753: Rational ClearCase Use in CodeWarrior 10.3 – Application Note 用户指南 User Guide 1 14 0 English 1239719097706725007507 PSP 281.2 KB None None documents None 1239719097706725007507 /docs/en/user-guide/MCF51_ACLIB.pdf 281239 /docs/en/user-guide/MCF51_ACLIB.pdf MCF51_ACLIB documents N 2009-04-14 MCF51 Advanced Control Library User&#8217;s Reference Manual /docs/en/user-guide/MCF51_ACLIB.pdf /docs/en/user-guide/MCF51_ACLIB.pdf User Guide N 132339537837198660 2023-06-18 pdf en Apr 14, 2009 132339537837198660 User Guide Y N MCF51 Advanced Control Library User&#8217;s Reference Manual 应用笔记软件 Application Note Software 2 15 Rev 0 English The Flexis&#8482; MM and JE series provides all the&#13;&#10;integrated analog peripherals that is needed to make user application perform as a breakthrough medical design.&#13;&#10;Integrated 16-bit ADC, 12-bit DAC, op-amps,&#13;&#10;Transimpedance amplifiers and USB connectivity make the Flexis&#8482; MM and JE ideal for medical applications.&#13;&#10;This document is intended to provide a quick reference to start using the analog peripherals in the Flexis&#8482; MM and JE series. The document provides a 1279257208571722505165 PSP 23.5 MB None None documents None 1279257208571722505165 /docs/en/application-note-software/ANQRUGSW.zip 23490970 /docs/en/application-note-software/ANQRUGSW.zip ANQRUGSW documents N 2010-07-15 Quick Reference User Guide for Analog Peripherals on the MM and JE Family /docs/en/application-note-software/ANQRUGSW.zip /docs/en/application-note-software/ANQRUGSW.zip Application Note Software N 789425793691620447 2022-12-07 zip en Jul 15, 2010 789425793691620447 Application Note Software D N Quick Reference User Guide for Analog Peripherals on the MM and JE Family 16 0 English 1272074867313720202219 PSP 888.5 KB None None documents None 1272074867313720202219 /docs/en/application-note-software/AN3412SW.zip 888482 /docs/en/application-note-software/AN3412SW.zip AN3412SW documents N 2010-04-23 Dynamic LCD Driver Using GPIO Pins /docs/en/application-note-software/AN3412SW.zip /docs/en/application-note-software/AN3412SW.zip Application Note Software N 789425793691620447 2022-12-07 zip en Apr 23, 2010 789425793691620447 Application Note Software D N Dynamic LCD Driver Using GPIO Pins 产品变更通知 Product Change Notice 1 17 0 English 1400655187257698150893 PSP 311.5 KB None None documents None 1400655187257698150893 /docs/en/product-change-notice/PCN16235.htm 311474 /docs/en/product-change-notice/PCN16235.htm PCN16235 documents N 2014-05-20 Copper Wire Conversion for Microcontroller and Microprocessor Devices /docs/en/product-change-notice/PCN16235.htm /docs/en/product-change-notice/PCN16235.htm Product Change Notice N 454076741825495278 2022-12-07 htm en May 20, 2014 454076741825495278 Product Change Notice D N Copper Wire Conversion for Microcontroller and Microprocessor Devices false 0 MCF51JE downloads zh-Hans true 1 Y PSP 产品变更通知 1 /docs/en/product-change-notice/PCN16235.htm 2014-05-20 1400655187257698150893 PSP 17 May 20, 2014 Product Change Notice None /docs/en/product-change-notice/PCN16235.htm English documents 311474 None 454076741825495278 2022-12-07 /docs/en/product-change-notice/PCN16235.htm Copper Wire Conversion for Microcontroller and Microprocessor Devices /docs/en/product-change-notice/PCN16235.htm documents 454076741825495278 Product Change Notice N en None D htm 0 N Copper Wire Conversion for Microcontroller and Microprocessor Devices 311.5 KB PCN16235 N 1400655187257698150893 参考手册 2 /docs/en/reference-manual/CFPRM.pdf 2001-07-26 C996188491014 PSP 4 Mar 8, 2005 Reference Manual This manual contains detailed information about the instruction set architecture (ISA) for all versions of ColdFire &#174; microprocessors. Within the ColdFire Family, each generation of hardware microarchitecture is known as a Version, beginning with the original Version 2 (V2) core implementation, the first native ColdFire processor implementation. The original ColdFire ISA was developed from a reduced version of the M68000 instruction set that was targeted to hit a &#8220;sweet-spot&#8221;. None /docs/en/reference-manual/CFPRM.pdf English documents 1706629 None 500633505221135046 2022-12-07 /docs/en/reference-manual/CFPRM.pdf ColdFire<sup>&#174;</sup> &#174; Family Programmer&#8217;s - Reference Manual /docs/en/reference-manual/CFPRM.pdf documents 500633505221135046 Reference Manual N en None Y pdf 3 N ColdFire<sup>&#174;</sup> &#174; Family Programmer&#8217;s - Reference Manual 1.7 MB CFPRM N C996188491014 /docs/en/reference-manual/MCF51JE256RM.pdf 2010-12-01 1291248438461720562504 PSP 3 Dec 1, 2010 Reference Manual 参考手册 The primary objective of this reference manual is to define the processor for software and hardware developers. The MCF51JE256 and MCF51JE128 series microcontrollers are systems-on-chip (SoCs) that are based on the ColdFire &#174; V1 core and: Operate at processor core speeds up to 50.33 MHz (peripherals operate at half of this speed) and integrate technologies that are important for today&#8217;s consumer and industrial applications, such as USB On-the-Go. None /docs/en/reference-manual/MCF51JE256RM.pdf English 4946036 None Reference Manual 2022-12-07 /docs/en/reference-manual/MCF51JE256RM.pdf MCF51JE256 - Reference Manual /docs/en/reference-manual/MCF51JE256RM.pdf documents 500633505221135046 Reference Manual N Y en None Y t877 pdf 2 N MCF51JE256 - Reference Manual 4.9 MB MCF51JE256RM N 1291248438461720562504 应用笔记 9 /docs/en/application-note/AN4695.pdf 2016-10-31 1366267658721722833617 PSP 5 Apr 17, 2013 Application Note This Application Note discusses important considerations and guidelines for implementing in-software flash programming on Kinetis and ColdFire+ MCUs None /docs/en/application-note/AN4695.pdf English documents 260008 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN4695.pdf Implementing in-software flash programming on Kinetis MCUs /docs/en/application-note/AN4695.pdf documents 645036621402383989 Application Note N en None pdf 0 N N Implementing in-software flash programming on Kinetis MCUs 260.0 KB AN4695 N 1366267658721722833617 /docs/en/application-note/ANPERIPHQRUG.pdf 2010-04-23 1272074387577746295880 PSP 6 Jul 15, 2010 Application Note The Flexis&#8482; MM and JE series provides all the&#13;&#10;integrated analog peripherals that is needed to make user application perform as a breakthrough medical design.&#13;&#10;Integrated 16-bit ADC, 12-bit DAC, op-amps,&#13;&#10;Transimpedance amplifiers and USB connectivity make the Flexis&#8482; MM and JE ideal for medical applications.&#13;&#10;This document is intended to provide a quick reference to start using the analog peripherals in the Flexis&#8482; MM and JE series. The document provides a None /docs/en/application-note/ANPERIPHQRUG.pdf English documents 2563318 None 645036621402383989 2022-12-07 /docs/en/application-note/ANPERIPHQRUG.pdf Quick Reference User Guide for Analog Peripherals on the MM and JE Family /docs/en/application-note/ANPERIPHQRUG.pdf documents 645036621402383989 Application Note N en None Y pdf 0 N Quick Reference User Guide for Analog Peripherals on the MM and JE Family 2.6 MB ANPERIPHQRUG N 1272074387577746295880 /docs/en/application-note/AN3412.pdf 2010-04-23 1272075138770713976182 PSP 7 Apr 26, 2010 Application Note This application note explains how the twisted nematic (TN) liquid crystal displays (LCDs) work and how these kinds of LCDs can be controlled using the GPIO pins of a microcontroller. There are two ways to control the TN LCDs, statically and dynamically. The driver discussed in this document is intended to drive dynamic LCDs. The dynamically driven LCDs require a pure AC voltage waveform applied to the electrodes of the LCD. Each electrode needs one backplane electrode and one frontplane terminal to be disp None /docs/en/application-note/AN3412.pdf English documents 5477882 None 645036621402383989 2022-12-07 /docs/en/application-note/AN3412.pdf Dynamic LCD Driver Using GPIO Pins /docs/en/application-note/AN3412.pdf documents 645036621402383989 Application Note N en None Y pdf 0 N Dynamic LCD Driver Using GPIO Pins 5.5 MB AN3412 N 1272075138770713976182 /docs/zh/application-note/AN4452.pdf 2016-10-31 1326899406187705806071zh PSP 8 Application Note None /docs/zh/application-note/AN4452.pdf Chinese documents 1718385 None 645036621402383989 2022-12-07 N /docs/zh/application-note/AN4452.pdf 采用TWR-LCD电路板显示eGUI /docs/zh/application-note/AN4452.pdf documents 645036621402383989 Application Note N zh None pdf 0 N N Display eGUI using TWR-LCD board 1.7 MB AN4452 N 1326899406187705806071 /docs/en/application-note/AN4116.pdf 2010-04-23 1272071979959717585300 PSP 9 Jul 30, 2010 Application Note This application note shows how to easily migrate the communication protocol C12.18 which is already implemented on the MCF51EM256 on to new devices.This is explained in the NXP application note titled Using the MCF51EM Family for Infrared Communication (document AN3938). None /docs/en/application-note/AN4116.pdf English documents 796412 None 645036621402383989 2022-12-07 /docs/en/application-note/AN4116.pdf Using the MM/JE Flexis<sup>&#174;</sup> Families for Infrared Communication /docs/en/application-note/AN4116.pdf documents 645036621402383989 Application Note N en None Y pdf 0 N Using the MM/JE Flexis<sup>&#174;</sup> Families for Infrared Communication 796.4 KB AN4116 N 1272071979959717585300 /secured/assets/documents/en/application-note/AN4752.pdf 2016-10-31 1370013855832696188368 PSP 10 May 31, 2013 Application Note Explaining how to add the FreeMASTER serial driver software to the embedded application and configure it. The FreeMASTER serial driver is a piece of code that enables an embedded application to communicate with the FreeMASTER PC application. Registration without Disclaimer /secured/assets/documents/en/application-note/AN4752.pdf English documents 2220944 None 645036621402383989 2024-07-15 Y /webapp/Download?colCode=AN4752&lang_cd=zh AN4752: FreeMASTER Usage, Serial Driver Implementation – Application Note /secured/assets/documents/en/application-note/AN4752.pdf documents 645036621402383989 Application Note N en Extended Y pdf 0 Y N AN4752: FreeMASTER Usage, Serial Driver Implementation – Application Note 2.2 MB AN4752 N 1370013855832696188368 /docs/en/application-note/AN4115.pdf 2010-04-23 1272070234970717037114 PSP 11 Jul 30, 2010 Application Note AN4115: This application note discusses a physical layer driver used to establish IrDA communication on NXP devices in the MM/JE Flexis<sup>&#174;</sup> families, using the Carrier Modulator Timer (CMT) as transmitter and a Timer/Pulse-Width Modulator (TPM) as receptor. It also explains a driver to handle a Secure Digital (SD) card through a Serial Peripheral Interface (SPI) module. None /docs/en/application-note/AN4115.pdf English documents 445848 None 645036621402383989 2022-12-07 /docs/en/application-note/AN4115.pdf AN4115, IrDA Driver and SD Card File System on MM/JE Flexis<sup>&#174;</sup> Families - Application Notes /docs/en/application-note/AN4115.pdf documents 645036621402383989 Application Note N en None Y pdf 0 N AN4115, IrDA Driver and SD Card File System on MM/JE Flexis<sup>&#174;</sup> Families - Application Notes 445.8 KB AN4115 N 1272070234970717037114 /docs/zh/application-note/AN4379.pdf 2016-10-31 1318880133881734730624zh PSP 12 Application Note None /docs/zh/application-note/AN4379.pdf Chinese documents 511834 None 645036621402383989 2022-12-07 N /docs/zh/application-note/AN4379.pdf USB大容量存储设备(MSD)引导加载程序 /docs/zh/application-note/AN4379.pdf documents 645036621402383989 Application Note N zh None pdf 0 N N USB Mass Storage Device (MSD) Bootloader 511.8 KB AN4379 N 1318880133881734730624 /docs/en/application-note/AN4753.pdf 2016-10-31 1369937932059742568603 PSP 13 May 30, 2013 Application Note Presenting the use of the Rational ClearCase version control system in CodeWarrior 10.3. It lists the files needed to maintain the project and describes how to install, set up, use, and uninstall the ClearCase plugin in CodeWarrior 10.3. The ClearCase plugin enables you to check files in and out directly from within CodeWarrior, making the work more effective. None /docs/en/application-note/AN4753.pdf English documents 477314 None 645036621402383989 2024-07-15 N /docs/en/application-note/AN4753.pdf AN4753: Rational ClearCase Use in CodeWarrior 10.3 – Application Note /docs/en/application-note/AN4753.pdf documents 645036621402383989 Application Note N en None Y pdf 0 N N AN4753: Rational ClearCase Use in CodeWarrior 10.3 – Application Note 477.3 KB AN4753 N 1369937932059742568603 应用笔记软件 2 /docs/en/application-note-software/ANQRUGSW.zip 2010-07-15 1279257208571722505165 PSP 15 Jul 15, 2010 Application Note Software The Flexis&#8482; MM and JE series provides all the&#13;&#10;integrated analog peripherals that is needed to make user application perform as a breakthrough medical design.&#13;&#10;Integrated 16-bit ADC, 12-bit DAC, op-amps,&#13;&#10;Transimpedance amplifiers and USB connectivity make the Flexis&#8482; MM and JE ideal for medical applications.&#13;&#10;This document is intended to provide a quick reference to start using the analog peripherals in the Flexis&#8482; MM and JE series. The document provides a None /docs/en/application-note-software/ANQRUGSW.zip English documents 23490970 None 789425793691620447 2022-12-07 /docs/en/application-note-software/ANQRUGSW.zip Quick Reference User Guide for Analog Peripherals on the MM and JE Family /docs/en/application-note-software/ANQRUGSW.zip documents 789425793691620447 Application Note Software N en None D zip Rev 0 N Quick Reference User Guide for Analog Peripherals on the MM and JE Family 23.5 MB ANQRUGSW N 1279257208571722505165 /docs/en/application-note-software/AN3412SW.zip 2010-04-23 1272074867313720202219 PSP 16 Apr 23, 2010 Application Note Software None /docs/en/application-note-software/AN3412SW.zip English documents 888482 None 789425793691620447 2022-12-07 /docs/en/application-note-software/AN3412SW.zip Dynamic LCD Driver Using GPIO Pins /docs/en/application-note-software/AN3412SW.zip documents 789425793691620447 Application Note Software N en None D zip 0 N Dynamic LCD Driver Using GPIO Pins 888.5 KB AN3412SW N 1272074867313720202219 数据手册 1 /docs/en/data-sheet/MCF51JE256.pdf 2010-04-30 1272665028703711826856 PSP 2 Aug 13, 2012 Data Sheet 数据手册 The MCF51JE256 series devices are members of the low-cost, low-power, high-performance ColdFire &#174; V1 family of 32-bit microcontrollers (MCUs). This MCF51JE256 has the following features: Up to 50.33 MHz ColdFire CPU, 256 K Flash, 32 KB System Random-access memory (RAM), 80 LQFP, 81 BGA. None /docs/en/data-sheet/MCF51JE256.pdf English 657930 None Data Sheet 2022-12-07 N /docs/en/data-sheet/MCF51JE256.pdf MCF51JE256/128 - Data Sheet /docs/en/data-sheet/MCF51JE256.pdf documents 980000996212993340 Data Sheet N Y en None Y t520 pdf 4 N N MCF51JE256/128 - Data Sheet 657.9 KB MCF51JE256 N 1272665028703711826856 用户指南 1 /docs/en/user-guide/MCF51_ACLIB.pdf 2009-04-14 1239719097706725007507 PSP 14 Apr 14, 2009 User Guide None /docs/en/user-guide/MCF51_ACLIB.pdf English documents 281239 None 132339537837198660 2023-06-18 /docs/en/user-guide/MCF51_ACLIB.pdf MCF51 Advanced Control Library User&#8217;s Reference Manual /docs/en/user-guide/MCF51_ACLIB.pdf documents 132339537837198660 User Guide N en None Y pdf 0 N MCF51 Advanced Control Library User&#8217;s Reference Manual 281.2 KB MCF51_ACLIB N 1239719097706725007507 简介 1 /docs/en/fact-sheet/MCF51JE256FS.pdf 2020-02-18 1271941518919716674641 PSP 1 Feb 18, 2020 Fact Sheet 简介 MCF51JE256FS: The MCF51JE256/128 (JE256/128) provides ultra-low-power operation, USB connectivity and high measurement accuracy, all in a single 32-bit microcontroller, allowing designers to develop a more fully featured system at a lower cost. The JE256/128 integrates high-resolution ADC and DAC modules and a rich peripheral set including a USB 2.0 host/device/OTG controller, multiple serial interfaces and an external bus interface. None /docs/en/fact-sheet/MCF51JE256FS.pdf English 268618 None Fact Sheet 2022-12-07 N /docs/en/fact-sheet/MCF51JE256FS.pdf MCF51JE256/128 Ultra-low-power MCU with USB connectivity - Fact Sheet /docs/en/fact-sheet/MCF51JE256FS.pdf documents 736675474163315314 Fact Sheet N Y en None Y t523 pdf 2 N N MCF51JE256/128 Ultra-low-power MCU with USB connectivity - Fact Sheet 268.6 KB MCF51JE256FS N 1271941518919716674641 true Y Products
