Layerscape® 1028A应用处理器

LS1028A 正常供应
Motion Control with TSN Using NXP's LS1028A Industrial Applications Processor

点击播放视频

Layerscape LS1028A应用处理器包括支持时间敏感网络(TSN)的以太网交换机和以太网控制器，面向工业和汽车业，可支持融合的IT和OT网络。

两个功能强大的64位Arm®v8内核支持工业控制的实时处理，以及物联网中边缘计算的虚拟机。内置GPU和LCD控制器使人机接口(HMI)系统支持新一代接口。

集成可信架构带有加密分流功能，可提供能够加密通信的可信平台，适用于安全的应用和服务。

Layerscape处理器是恩智浦EdgeVerse™边缘计算平台的一部分。

框图

Layerscape LS1028A Block Diagram

Layerscape LS1028A Block Diagram
获取框图PDF

特征

  • 面向工业应用的Armv8双处理器
  • 4端口时间敏感网络交换机
  • 2个具有时间敏感网络功能的以太网控制器
  • GPU和LCD控制器
  • 加密分流引擎可配置
  • 集成的可信架构
  • PCI Express
  • CAN总线
