Kinetis® KW41Z-2.4 GHz双模式：BLE和802.15.4无线连接微控制器(MCU)，基于Arm® Cortex®-M0+内核

KW41Z
正常供应
Thread Smart Home Model

点击播放视频

KW41Z是一款超低功耗、高集成度的单芯片器件，让便携式、超低功耗的嵌入式系统具备Bluetooth® Low Energy (BLE) v4.2和IEEE® 802.15.4射频连接。应用包括便携式医疗设备、可穿戴的运动和健身设备、AV遥控器、电脑键盘和鼠标、游戏控制器、门禁安防系统、智能能源和家庭网络。

KW41Z无线MCU集成了一个2.4 GHz收发器，支持FSK/GFSK和O-QPSK调制，一个ARM® Cortex®-M0+ CPU，高达512KB闪存和128 KB SRAM，802.15.4分组处理器，硬件安全和外围设备，可满足目标应用的需求。

KW41Z是真正单芯片设计的理想解决方案，单芯片设计需要在Bluetooth Low Energy网络和Thread等基于802.15.4的网络上进行并行通信。此多模功能支持通过移动设备使用Bluetooth Low Energy进行直接通信，并且可纳入网状网进行本地和远程控制/监控。

框图

Kinetis® W Series KW40Z MCUs Block Diagram

Kinetis<sup>&#174;</sup> W Series KW41Z MCUs Block Diagram
获取框图PDF

Features

多协议无线电

  • 符合2.4 GHz Bluetooth Low Energy V4.2
  • 符合IEEE Std. 802.15.4标准
  • 典型的接收灵敏度(BLE) = -95 dBm
  • 典型的接收灵敏度(802.15.4) = -100 dBm
  • 发射器输出功率可设置，高达+3.5 dBm

内核和存储器

  • 高达48 MHz Arm® Cortex®-M0+内核
  • 高达512 KB闪存
  • 高达128 KB SRAM
  • 卓越的共存性能
  • 集成式换衡器可降低系统成本和减少PCB电路板空间

功耗低，工作电压范围

  • 9个低功耗模式，根据应用需求提供优化的电源
  • 典型接收/发送电流(直流/支持直流)： 6.5 mA / 8.4 mA
  • 典型接收/发送电流(直流/支持直流)： 6.8/6.1 mA
  • 旁路电压：1.71V至3.6V
  • DCDC转换器降压配置：2.1V至4.2V
  • DCDC转换器升压配置：0.9V 至1.795V

模拟模块

  • 16位模数转换器(ADC)
  • 12位数模转换器 (DAC)
  • 6位高速模拟比较器(CMP)

安全性

  • AES-128加速器(AESA)，真随机数生成器(TRNG)

支持软件

  • BLE主机协议栈和资料
  • 通用FSK链路层软件
  • Thread、802.15.4 MAC、SMAC
  • Thread + BLE堆栈(并行运行)
  • Kinetis®软件开发套件(SDK)
  • FreeRTOS内核和裸机非抢占任务调度器
  • 支持MCUXpresso和IAR

更多

对比表

Kinetis KW41Z系列解决方案

部件编号 无线连接协议 存储器 封装大小 硬件开发工具
MKW41Z512VHT4 Bluetooth Low Energy和IEEE 802.15.4 512 KB闪存，
128 KB RAM		 7 mm x 7 mm x 1 mm
48引脚层压QFN封装		 FRDM-KW41Z
USB-KW41Z
MKW41Z256VHT4 256 KB闪存，
64 KB SRAM
MKW41Z512CAT4R 512 KB闪存，
128 KB RAM		 3.9 mm x 3.8 mm
75引脚WLCSP
MKW31Z512VHT4 Bluetooth Low Energy 512 KB闪存，
128 KB RAM		 7 mm x 7 mm x 1 mm
48引脚层压QFN封装
MKW31Z256VHT4 256 KB闪存，
64 KB SRAM
MKW31Z512CAT4R 512 KB闪存，
128 KB RAM		 3.9 mm x 3.8 mm
75引脚WLCSP
MKW21Z512VHT4 IEEE 802.15.4 512 KB闪存，
128 KB RAM		 7 mm x 7 mm x 1 mm
48引脚层压QFN封装
MKW21Z256VHT4 256 KB闪存，
64 KB SRAM

购买/参数

3 结果

包含 0 不推荐用于新设计

部件

展开描述

订购

计算机辅助设计模型

安全

802.15.4 Receive Sensitivity (dBm)

人机接口

IEEE 802.15.4 Radio

GPIO

MKW41Z256VHT4
数据手册

CRC

-100

touch system interface

Y

25

MKW41Z512CAT4
数据手册

—

—

—

—

—

MKW41Z512VHT4
数据手册

AES-D, CRC, RNG

—

touch system interface

Y

25
