I2C总线Fm+, 精度为1℃, 数字温度传感器和热看门狗

更多

产品详情

功能

基本信息

  • 提供LM75系列的引脚到引脚替换,但总线上支持多达27个器件
  • 电源电压范围:2.7 V至5.5 V
  • 温度范围:-55 °C至+125 °C
  • 频率范围:20 Hz至1 MHz,具有SMBus超时功能,避免总线挂起
  • 1 MHz超快速模式(Fm+) 30 mA SDA驱动器可在一条总线上连接更多器件,同时向下兼容快速模式和标准模式
  • 11位ADC,温度分辨率为0.125 °C
  • 温度精度:
    • ±1 °C(最大值,-25 °C至+100 °C)
    • ±2 °C(最大值,-55 °C至+125 °C)
  • 工作时具有可编程温度阈值和迟滞设定点
  • 关断模式下电源电流低于1.0 μA,可节省电能
  • 上电时可单独作为恒温器使用
  • ESD保护根据JESD22-A114标准超过2000 V HBM和根据JESD22-C101标准超过1000 V CDM
  • 根据JEDEC标准JESD78完成超过100 mA的锁定测试
  • 小型8引脚封装类型:SO8、TSSOP8和2 mm x 3 mm HWSON8
  • 小型6引脚封装类型:TSOP6

产品长期供货计划

  • 该产品包含在恩智浦产品长期供货计划中,确保为您的嵌入式设计提供稳定的产品供应。PCT2075DP包含在15年产品长期供货计划中

对照表

所有器件具有相同的I²C接口、LM75型寄存器、温度精度和电源范围/功耗

购买/参数










































































































N true 0 PSPPCT2075zh 10 包装信息 Packing Information t935 3 封装信息 Package Information t790 3 支持信息 Supporting Information t531 2 数据手册 Data Sheet t520 1 选型指南 Selector Guide t528 1 zh zh zh 数据手册 Data Sheet 1 1 10.1 English PCT2075 data sheet. 1442057179810732184638 PSP 511.4 KB None None documents None 1442057179810732184638 /docs/en/data-sheet/PCT2075.pdf 511371 /docs/en/data-sheet/PCT2075.pdf PCT2075 documents N N 2016-10-08 I2C-bus Fm+, 1 degree C accuracy, digital temperature sensor and thermal watchdog /docs/en/data-sheet/PCT2075.pdf /docs/en/data-sheet/PCT2075.pdf Data Sheet N 980000996212993340 2023-08-23 pdf N en Sep 15, 2021 980000996212993340 Data Sheet Y N I2C-bus Fm+, 1 degree C accuracy, digital temperature sensor and thermal watchdog PDF 封装信息 Package Information 3 2 1.1 English Outline and soldering footprint drawings of SO8 package 1455079789802691427607 PSP 175.4 KB None None documents None 1455079789802691427607 /docs/en/package-information/SOT96-1.pdf 175406 /docs/en/package-information/SOT96-1.pdf SOT96-1 documents N N 2016-10-08 Plastic, small outline package; 8 terminals; 1.27 mm pitch; 4.9 mm x 3.9 mm x 1.75 mm body /docs/en/package-information/SOT96-1.pdf /docs/en/package-information/SOT96-1.pdf Package Information N 302435339416912908 2024-10-24 pdf N en Jan 9, 2017 302435339416912908 Package Information Y N Plastic, small outline package; 8 terminals; 1.27 mm pitch; 4.9 mm x 3.9 mm x 1.75 mm body PDF 3 1.1 English 1455079767240717683478 PSP 195.1 KB None None documents None 1455079767240717683478 /docs/en/package-information/SOT1069-2.pdf 195064 /docs/en/package-information/SOT1069-2.pdf SOT1069-2 documents N N 2016-06-10 HWSON8: plastic thermal enhanced very very thin small outline package, no leads; 8 terminals; /docs/en/package-information/SOT1069-2.pdf /docs/en/package-information/SOT1069-2.pdf Package Information N 302435339416912908 2024-03-12 pdf N en Jun 10, 2016 302435339416912908 Package Information Y N HWSON8: plastic thermal enhanced very very thin small outline package, no leads; 8 terminals; 4 1.0 English 1455079182633718471287 PSP 255.0 KB None None documents None 1455079182633718471287 /docs/en/package-information/SOT1353-1.pdf 255000 /docs/en/package-information/SOT1353-1.pdf SOT1353-1 documents N N 2016-02-12 plastic surface-mounted package (TSOP6); 6 leads /docs/en/package-information/SOT1353-1.pdf /docs/en/package-information/SOT1353-1.pdf Package Information N 302435339416912908 2022-12-07 pdf N en Feb 8, 2016 302435339416912908 Package Information Y N plastic surface-mounted package (TSOP6); 6 leads 包装信息 Packing Information 3 5 1.0 English 1442131193747703574717 PSP 200.5 KB None None documents None 1442131193747703574717 /docs/en/packing/SOT1069-2_147.pdf 200499 /docs/en/packing/SOT1069-2_147.pdf SOT1069-2_147 documents N N 2014-05-06 HWSON8; Reel pack, SMD, 7"Q2/T3 Turned 90 degree product orientationOrderable part number ending, 147 or ZOrdering code (12NC) ending 147 /docs/en/packing/SOT1069-2_147.pdf /docs/en/packing/SOT1069-2_147.pdf Packing Information N 145666923842250347 2024-03-13 pdf N en May 6, 2014 145666923842250347 Packing Information Y N HWSON8; Reel pack, SMD, 7"Q2/T3 Turned 90 degree product orientationOrderable part number ending, 147 or ZOrdering code (12NC) ending 147 6 2.0 English 1442131194585714093488 PSP 237.4 KB Registration without Disclaimer None documents Extended 1442131194585714093488 /secured/assets/documents/en/packing/SOT96-1_118.pdf 237384 /secured/assets/documents/en/packing/SOT96-1_118.pdf SOT96-1_118 documents Y N 2013-04-19 SO8; Reel pack; SMD, 13" Q1/T1 Standard product orientation Orderable part number ending ,118 or J Ordering code (12NC) ending 118 /webapp/Download?colCode=SOT96-1_118&lang_cd=zh /secured/assets/documents/en/packing/SOT96-1_118.pdf Packing Information N 145666923842250347 2024-03-13 pdf Y en Apr 19, 2013 145666923842250347 Packing Information Y N SO8; Reel pack; SMD, 13" Q1/T1 Standard product orientation Orderable part number ending ,118 or J Ordering code (12NC) ending 118 7 1.0 English Packing info for TSSOP8 package 1442131705242712040486 PSP 218.8 KB None None documents None 1442131705242712040486 /docs/en/packing/SOT505-1_118.pdf 218803 /docs/en/packing/SOT505-1_118.pdf SOT505-1_118 documents N N 2013-04-17 TSSOP8; Reel pack; SMD, 13"Q1/T1 Standard product orientationOrderable part number ending ,118 or JOrdering code (12NC) ending 118 /docs/en/packing/SOT505-1_118.pdf /docs/en/packing/SOT505-1_118.pdf Packing Information N 145666923842250347 2024-10-21 pdf N en Apr 15, 2013 145666923842250347 Packing Information Y N TSSOP8; Reel pack; SMD, 13"Q1/T1 Standard product orientationOrderable part number ending ,118 or JOrdering code (12NC) ending 118 选型指南 Selector Guide 1 8 2.1 English 1442126252734722248255 PSP 3.3 MB None None documents None 1442126252734722248255 /docs/en/product-selector-guide/75017085.pdf 3301382 /docs/en/product-selector-guide/75017085.pdf 75017085 documents N N 2016-10-08 Application guide: Flat-panel TV sets /docs/en/product-selector-guide/75017085.pdf /docs/en/product-selector-guide/75017085.pdf Selector Guide N 553557935274807777 2025-02-11 pdf N en Mar 12, 2012 553557935274807777 Selector Guide Y N Application guide: Flat-panel TV sets 支持信息 Supporting Information 2 9 1.0 English Reflow Soldering temperature profile 1442122749741692602431 PSP 34.6 KB None None documents None 1442122749741692602431 /docs/en/supporting-information/Reflow_Soldering_Profile.pdf 34577 /docs/en/supporting-information/Reflow_Soldering_Profile.pdf REFLOW_SOLDERING_PROFILE documents N N 2016-10-08 Reflow Soldering Profile /docs/en/supporting-information/Reflow_Soldering_Profile.pdf /docs/en/supporting-information/Reflow_Soldering_Profile.pdf Supporting Information N 371282830530968666 2024-11-28 pdf N en Feb 17, 2014 371282830530968666 Supporting Information Y N Reflow Soldering Profile 10 1.0 English Footprint for Wave Soldering 1442126382106720903168 PSP 8.3 KB None None documents None 1442126382106720903168 /docs/en/supporting-information/SO-SOJ-WAVE.pdf 8260 /docs/en/supporting-information/SO-SOJ-WAVE.pdf SO-SOJ-WAVE documents N N 2013-07-15 Footprint for Wave Soldering /docs/en/supporting-information/SO-SOJ-WAVE.pdf /docs/en/supporting-information/SO-SOJ-WAVE.pdf Supporting Information N 371282830530968666 2024-10-21 pdf N en Oct 8, 2009 371282830530968666 Supporting Information Y N Footprint for Wave Soldering false 0 PCT2075 downloads zh-Hans true 1 Y PSP Y Y 包装信息 3 /docs/en/packing/SOT1069-2_147.pdf 2014-05-06 1442131193747703574717 PSP 5 May 6, 2014 Packing Information None /docs/en/packing/SOT1069-2_147.pdf English documents 200499 None 145666923842250347 2024-03-13 N /docs/en/packing/SOT1069-2_147.pdf HWSON8; Reel pack, SMD, 7"Q2/T3 Turned 90 degree product orientationOrderable part number ending, 147 or ZOrdering code (12NC) ending 147 /docs/en/packing/SOT1069-2_147.pdf documents 145666923842250347 Packing Information N en None Y pdf 1.0 N N HWSON8; Reel pack, SMD, 7"Q2/T3 Turned 90 degree product orientationOrderable part number ending, 147 or ZOrdering code (12NC) ending 147 200.5 KB SOT1069-2_147 N 1442131193747703574717 /secured/assets/documents/en/packing/SOT96-1_118.pdf 2013-04-19 1442131194585714093488 PSP 6 Apr 19, 2013 Packing Information Registration without Disclaimer /secured/assets/documents/en/packing/SOT96-1_118.pdf English documents 237384 None 145666923842250347 2024-03-13 Y /webapp/Download?colCode=SOT96-1_118&lang_cd=zh SO8; Reel pack; SMD, 13" Q1/T1 Standard product orientation Orderable part number ending ,118 or J Ordering code (12NC) ending 118 /secured/assets/documents/en/packing/SOT96-1_118.pdf documents 145666923842250347 Packing Information N en Extended Y pdf 2.0 Y N SO8; Reel pack; SMD, 13" Q1/T1 Standard product orientation Orderable part number ending ,118 or J Ordering code (12NC) ending 118 237.4 KB SOT96-1_118 N 1442131194585714093488 /docs/en/packing/SOT505-1_118.pdf 2013-04-17 1442131705242712040486 PSP 7 Apr 15, 2013 Packing Information Packing info for TSSOP8 package None /docs/en/packing/SOT505-1_118.pdf English documents 218803 None 145666923842250347 2024-10-21 N /docs/en/packing/SOT505-1_118.pdf TSSOP8; Reel pack; SMD, 13"Q1/T1 Standard product orientationOrderable part number ending ,118 or JOrdering code (12NC) ending 118 /docs/en/packing/SOT505-1_118.pdf documents 145666923842250347 Packing Information N en None Y pdf 1.0 N N TSSOP8; Reel pack; SMD, 13"Q1/T1 Standard product orientationOrderable part number ending ,118 or JOrdering code (12NC) ending 118 218.8 KB SOT505-1_118 N 1442131705242712040486 封装信息 3 /docs/en/package-information/SOT96-1.pdf 2016-10-08 1455079789802691427607 PSP 2 Jan 9, 2017 Package Information Outline and soldering footprint drawings of SO8 package PDF None /docs/en/package-information/SOT96-1.pdf English documents 175406 None 302435339416912908 2024-10-24 N /docs/en/package-information/SOT96-1.pdf Plastic, small outline package; 8 terminals; 1.27 mm pitch; 4.9 mm x 3.9 mm x 1.75 mm body /docs/en/package-information/SOT96-1.pdf documents 302435339416912908 Package Information N en None Y pdf 1.1 N N Plastic, small outline package; 8 terminals; 1.27 mm pitch; 4.9 mm x 3.9 mm x 1.75 mm body 175.4 KB SOT96-1 N 1455079789802691427607 /docs/en/package-information/SOT1069-2.pdf 2016-06-10 1455079767240717683478 PSP 3 Jun 10, 2016 Package Information None /docs/en/package-information/SOT1069-2.pdf English documents 195064 None 302435339416912908 2024-03-12 N /docs/en/package-information/SOT1069-2.pdf HWSON8: plastic thermal enhanced very very thin small outline package, no leads; 8 terminals; /docs/en/package-information/SOT1069-2.pdf documents 302435339416912908 Package Information N en None Y pdf 1.1 N N HWSON8: plastic thermal enhanced very very thin small outline package, no leads; 8 terminals; 195.1 KB SOT1069-2 N 1455079767240717683478 /docs/en/package-information/SOT1353-1.pdf 2016-02-12 1455079182633718471287 PSP 4 Feb 8, 2016 Package Information None /docs/en/package-information/SOT1353-1.pdf English documents 255000 None 302435339416912908 2022-12-07 N /docs/en/package-information/SOT1353-1.pdf plastic surface-mounted package (TSOP6); 6 leads /docs/en/package-information/SOT1353-1.pdf documents 302435339416912908 Package Information N en None Y pdf 1.0 N N plastic surface-mounted package (TSOP6); 6 leads 255.0 KB SOT1353-1 N 1455079182633718471287 支持信息 2 /docs/en/supporting-information/Reflow_Soldering_Profile.pdf 2016-10-08 1442122749741692602431 PSP 9 Feb 17, 2014 Supporting Information Reflow Soldering temperature profile None /docs/en/supporting-information/Reflow_Soldering_Profile.pdf English documents 34577 None 371282830530968666 2024-11-28 N /docs/en/supporting-information/Reflow_Soldering_Profile.pdf Reflow Soldering Profile /docs/en/supporting-information/Reflow_Soldering_Profile.pdf documents 371282830530968666 Supporting Information N en None Y pdf 1.0 N N Reflow Soldering Profile 34.6 KB REFLOW_SOLDERING_PROFILE N 1442122749741692602431 /docs/en/supporting-information/SO-SOJ-WAVE.pdf 2013-07-15 1442126382106720903168 PSP 10 Oct 8, 2009 Supporting Information Footprint for Wave Soldering None /docs/en/supporting-information/SO-SOJ-WAVE.pdf English documents 8260 None 371282830530968666 2024-10-21 N /docs/en/supporting-information/SO-SOJ-WAVE.pdf Footprint for Wave Soldering /docs/en/supporting-information/SO-SOJ-WAVE.pdf documents 371282830530968666 Supporting Information N en None Y pdf 1.0 N N Footprint for Wave Soldering 8.3 KB SO-SOJ-WAVE N 1442126382106720903168 数据手册 1 /docs/en/data-sheet/PCT2075.pdf 2016-10-08 1442057179810732184638 PSP 1 Sep 15, 2021 Data Sheet PCT2075 data sheet. PDF None /docs/en/data-sheet/PCT2075.pdf English documents 511371 None 980000996212993340 2023-08-23 N /docs/en/data-sheet/PCT2075.pdf I2C-bus Fm+, 1 degree C accuracy, digital temperature sensor and thermal watchdog /docs/en/data-sheet/PCT2075.pdf documents 980000996212993340 Data Sheet N en None Y pdf 10.1 N N I2C-bus Fm+, 1 degree C accuracy, digital temperature sensor and thermal watchdog 511.4 KB PCT2075 N 1442057179810732184638 选型指南 1 /docs/en/product-selector-guide/75017085.pdf 2016-10-08 1442126252734722248255 PSP 8 Mar 12, 2012 Selector Guide None /docs/en/product-selector-guide/75017085.pdf English documents 3301382 None 553557935274807777 2025-02-11 N /docs/en/product-selector-guide/75017085.pdf Application guide: Flat-panel TV sets /docs/en/product-selector-guide/75017085.pdf documents 553557935274807777 Selector Guide N en None Y pdf 2.1 N N Application guide: Flat-panel TV sets 3.3 MB 75017085 N 1442126252734722248255 true Y Products
