MCF5253评估板

M5253EVB

滚动图片以放大

M5253EVB is a versatile single-board computer based on the MCF5253 ColdFire®® processor. 在各种应用中，它可以用作一个基于微处理器的强大控制器。它是一个可用于参考设计、开发/评估、培训和教育的完整微型计算机系统。用户只需连接一个RS-232兼容终端(或带终端仿真软件的个人电脑)和电源，就能拥有一个全功能系统。

产品详情

支持的器件

处理器和微控制器

ColdFire® V2处理器

  • MCF525X: 集成式ColdFire® V2微处理器

特征

微控制器

  • MCF5253 32-Bit ColdFire®© Controller

其他存储器

  • SDRAM
  • 闪存ROM

Serial Interfaces

  • USB 2.0 High-Speed OTG Connector
  • IDE/ATA接口
  • CAN Transceiver to DB-9 Connector
  • RS-232 transceiver to DB-9 Connector
  • SD卡接口
  • TFT显示界面
  • 键盘(ATD)

Digital and Analog Audio I/O connections

  • DAC接到耳机插口
  • 插入ADC的RCA Phono插头
  • 音频输出到EBU光发射器
  • EBU光接收器接到音频输入
