i.MX 6ULL应用处理器_Arm® Cortex®-A7单核，频率为900 MHz

点击播放视频

i.MX 6ULL是一个高功效、高性价比应用处的理器系列，采用单个Arm Cortex-A7内核，运行速度高达528 MHz。i.MX 6ULL应用处理器包括一个集成的电源管理模块，降低了外接电源的复杂性，并简化了上电时序。这个系列的每个处理器提供多种存储器接口，其中包括16位LPDDR2、DDR3、DDR3L、原始和管理的NAND闪存、NOR闪存、eMMC、Quad SPI和各种其他接口，用于连接外围设备，如WLAN、Bluetooth^®、GPS、显示器和摄像头传感器。

产品详情

框图

i.MX 6ULL Block Diagram

获取框图PDF

特征

CPU复合器件

Cortex-A7内核，运行频率900 MHz，128 KB L2缓存

显示

并行LCD显示，分辨率高达WXGA (1366x768)
8/10/16/24位并行摄像头传感器接口
电泳显示屏控制器支持直接驱动E-Ink EPD面板，分辨率高达2048x1536，工作频率106 Hz

存储器

16位LP-DDR2, DDR3/DDR3L
8/16位并行NOR FLASH / PSRAM
双通道Quad-SPI NOR FLASH
8位原始NAND FLASH与40位ECC

数据连接

2个MMC 4.5/SD 3.0/SDIO端口
2个USB 2.0 OTG，HS/FS，器件或主机，带PHY接口
音频接口包括3个I2S/SAI, S/PDIF Tx/Rx
2个10/100以太网，支持IEEE 1588协议
2个12位ADC，高达10个输入通道，以及电阻式触摸控制器(4线/5线)

先进的电源管理

部分PMU集成

安全性

安全模块：TRNG，加密引擎(带DPA的AES，TDES/SHA/RSA)，安全引导

封装

14x14 289 MAPBGA 0.8mm间距
9x9 272 MAPBGA 0.5 mm间距
