SPI Real-Time Clock/Calendar

PCF2123
正常供应
NXP’s Real-Time Clocks

点击播放视频

PCF2123是一款CMOS实时时钟(RTC)和日历，最适合低功率应用。通过串行外设接口(SPI-bus)以6.25 Mbit/s的最大数据速率串行传送数据。还提供警报和定时器功能，可在中断引脚上生成唤醒信号。偏移寄存器允许对时钟进行精细调整。

框图

选择框图:

PCF2123 Block Diagram

PCF2123 Block Diagram

Block diagram: PCF2123TS, PCF2123U

获取框图PDF

功能

主要特性

  • 实时时钟基于32.768 kHz石英晶体提供年、月、日、周、时、分和秒
  • 运行时的低备用电流：VDD = 2.0 V和Tamb = 25 ℃时典型值为100 nA
  • 分辨率：秒至年
  • 看门狗功能
  • 具备中断能力的自由可编程定时器和警报
  • 时钟工作电压：1.1 V至5.5 V
  • 带分离式可组合数据输入和输出的3线路SPI总线
  • VDD = 1.8 V至5.5 V时的串行接口
  • 1秒钟或1分钟中断输出
  • CL = 7 pF的集成振荡器负载电容
  • 内部电源上电复位(POR)
  • 开漏中断和时钟输出引脚
  • 用于频率调节的可编程偏移寄存器

产品长期供货计划

  • 该产品包含在恩智浦产品长期供货计划中，为您的嵌入式设计确保产品的供货稳定性。PCF2123BS/1和PCF2123TS/1包含在15年产品长期供货计划中

购买/参数

3 结果

包含 0 不推荐用于新设计

部件

展开描述

订购

计算机辅助设计模型

状态

预算报价（不含税）

分辨率

Interface

VDD (interface)

watchdog timer

Programmable alarm

countdown timer

特性

VDD (clock)

leap year tracking

IDD (nA)

temperature compensation

AEC-Q100 compliant

PCF2123BS
数据手册

正常供应

1K @ CNY3.37

1 sec to year

SPI

1.8 to 5.5

yes

yes

yes

lowest power

1.1 to 5.5

yes

110

no

no

PCF2123TS
数据手册

正常供应

1K @ CNY3.59

1 sec to year

SPI

1.8 to 5.5

yes

yes

yes

lowest power

1.1 to 5.5

yes

110

no

no

PCF2123U
数据手册

正常供应

1K @ CNY2.44 - 1K @ CNY2.80

1 sec to year

SPI

1.8 to 5.5

yes

yes

yes

lowest power

1.1 to 5.5

yes

110

no

no
