Low Cost 32-Bit Microprocessor (Including HC000, HC001, EC000 and SEC000)
- 建议不要在新设计中使用本页介绍的产品。
The industry's lowest cost 32-bit microprocessor, the MC68000 offers an excellent low cost
entry point to the M68000 Family. The MC68HC000 is a CMOS version of the original
MC68000. The MC68HC001 is also a CMOS version of the original MC68000 with 8-/16-bit selectable data bus. The MC68EC000 version provides a lower cost 68000 solution. The MC68SEC000
version provides a static, low power implementation consuming only 15.0mA in normal 3.3V
operation and 0.5mA in static standby mode.
产品详情
框图
Features
- 32 Bit Data and Address Registers
- 16 MByte Direct Addressing Range
- 56 Powerful Instructions
- Memory Mapped Input/Output
- 14 Addressing Modes
- 2 MIPS at 20MHz
- Available in 8, 10, 12, 16 and 20 MHz speeds (MC68HC000 and MC68EC000)
- Available in 10, 16 and 20 MHz speeds (MC68SEC000)
- Available in 8, 10, 12 and 16 MHz speeds (MC68HC001)
部件编号包含： MC68SEC000AA10, MC68SEC000AA16, MC68SEC000AA20, MC68SEC000AA20B1, MC68SEC000AE10, MC68SEC000AE16, MC68SEC000AE20, MC68SEC000CAA10, MC68SEC000CAA16, MC68SEC000CAA20.
