Kinetis® K65-180 MHz，双高速和全速USB，2MB闪存，防篡改微控制器(MCU)，基于Arm® Cortex®-M4 内核

K65_180 正常供应
Kinetis<sup>®</sup> MCU支持工具：Kinetis软件开发套件(SDK)概述

点击播放视频

Kinetis® K65 180 MHz IEEE® 1588以太网MCU基于Arm® Cortex®-M4F内核，适合需要安全加密、篡改检测、高存储器密度的应用，还能以超低功耗实现高处理效率。该系列提供高速USB，带集成高速USB物理收发器、SDRAM控制器、全速无晶体USB支持等功能，同时还与Kinetis产品组合共享综合的支持工具和可扩展性。

框图

Kinetis K65/K66 MCU Family Block Diagram

Kinetis K65/K66 MCU Family Block Diagram
获取框图PDF

特征

性能

  • 基于Arm® Cortex®-M4F内核构建，运行频率为180 MHz，带单精度浮点单元和8KB缓存。
  • 多达32通道的DMA用于外设和存储器，可以降低CPU负载，实现更快的系统吞吐，并在停止模式提供异步支持。
  • 交叉开关支持并发多主设备总线访问，增加总线带宽
  • 独立的闪存Bank可以并发执行代码和固件更新，既不会影响性能，也无需复杂的编码例程

超低功耗

  • 灵活的低功耗模式，提供电源和时钟门控，可以实现最佳的外设活动和恢复时间。运行功耗降至µA/MHz，静态功耗降至9.0 µA，支持全状态保留，不到6 µS即可唤醒。静态功耗可低至254A(VLLS0)。
  • 工作电压降至1.71 V时，仍可实现完整的存储器和模拟操作，延长了电池使用时间
  • 低漏电唤醒单元，带有多达7个内置模块和20个引脚，可作为低漏电停止(LLS)模式和超低漏电停止(VLLS)模式的唤醒源
  • 低功耗定时器支持系统在低功耗状态下持续运行

存储器

  • 高达2 MB闪存。支持快速访问，具备高可靠性，提供4级安全保护
  • 256 KB SRAM
  • FlexMemory：高达4 KB用户可分段的字节写入/擦除EEPROM，适用于数据表/系统数据。此外，高达256 KB的FlexNVM还可用于额外程序代码、数据或EEPROM备份

混合信号功能

  • 两个分辨率可配置的高速16位模数转换器(ADC)。
  • 两个12位数模转换器(DAC)，可以为音频应用生成模拟波形
  • 4个高速比较器，可通过将脉宽调制(PWM)置于安全状态，提供快速准确的电机过流保护
  • 模拟参考电压可为模拟模块、ADC和DAC提供精确的参考值，代替外部参考电压，降低系统成本

定时和控制

  • 最多两个16位低功耗PWM定时器模块，两个8通道电机控制/通用/ PWM定时器和两个两路四解码器/通用定时器
  • 16位低功耗定时器，以及4个32位周期中断定时器
  • 载波调制定时器，用于在遥控应用中生成红外线波形
  • 4通道32位周期中断定时器可为实时操作系统任务调度程序提供时基，还可为ADC转换和可编程延迟模块提供触发源

人机接口

  • 带有多达16路输入的硬件触摸传感接口。可在所有低功耗模式下运行(启用时只增加极小的电流)。通过硬件实现避免了软件轮询方法。高灵敏度，允许使用厚达5毫米厚度的贴膜

数据连接与通信

  • 带硬件时间戳功能的IEEE 1588以太网MAC为实时工业控制提供高精度时钟同步
  • 双USB，通过集成式HS收发器支持高速(HS)，通过集成式FS收发器支持全速(FS)。带嵌入式48 MHz振荡器的智能式设计，可采用FS USB无晶振系统设计。
  • 一个低功率UART(LPUART)，以及5个标准的UART，带ISO7816智能卡支持。
  • IC间音频传输(I²S)串行接口，用于接入音频系统
  • 两个CAN模块，适用于工业网络桥接
  • 3个SPI和4个I²C

可靠性、安全性和安防

  • 存储器保护单元可为交叉开关上的所有主设备提供存储器保护，提高软件可靠性
  • 循环冗余校验引擎可验证存储器内容和通信数据，提高系统可靠性
  • 时钟独立的COP可防止时钟偏移或代码失控，适用于故障安全型应用(例如，针对家用电器的IEC 60730安全标准)
  • 如果发生看门狗事件，外部看门狗监控器可将输出引脚置于安全状态外部组件
  • 系统安全性，支持硬件加密、随机数发生器、带实时时钟的篡改检测以及独立电池电源。安全的密钥存储带有内部/外部篡改检测功能，适用于不安全的闪存、温度、时钟、电源电压变化和物理攻击检测等

更多

购买/参数

4 结果

包含 0 不推荐用于新设计

部件

展开描述

订购

计算机辅助设计模型

状态

内核类型

运行频率[最高]（MHz）

SRAM (kB)

Flash (kB)

EEPROM (kB)

UART

SPI

I2C

USB Controllers

CAN

以太网

GPIO

ADC (16 bit)

16-bit PWM

安全

电源电压[最小]（V）

电源电压[最大]（V）

封装类型

封装端接数

Package Dimensions (LxWxZ (mm))

Package Pitch (mm)

Ambient Operating Temperature (Min to Max) (℃)

MK65FN2M0CAC18
数据手册

正常供应

Arm Cortex-M0

180

—

2048

—

—

—

4

2

2

1

116

2

1

CA, CRC, RNG, TD

1.71

3.6

—

—

—

—

-40 to 85

MK65FN2M0VMI18
数据手册

正常供应

Arm Cortex-M4

180

256

2048

—

6

3

4

2

2

—

116

2

24

CA, CRC, RNG, TD

1.71

3.6

LFBGA169

169

9 x 9 x 1.15

0.65

-40 to 105

MK65FX1M0CAC18
数据手册

正常供应

Arm Cortex-M4

180

256

—

0

6

3

4

2

2

—

116

2

24

CA, CRC, RNG, TD

1.71

3.6

—

—

—

—

-40 to 85

MK65FX1M0VMI18
数据手册

正常供应

Arm Cortex-M4

180

256

1280

0

6

3

4

2

2

—

116

2

24

CA, CRC, RNG, TD

1.71

3.6

LFBGA169

169

9 x 9 x 1.15

0.65

-40 to 105
