Microcontroller
The NXP® MC68HC705P6A is an EPROM version of the MC68HC05P6 microcontroller. It is a low-cost combination of an M68HC05 Family microprocessor with a 4-channel, 8-bit analog-to-digital (A/D) converter, a 16-bit timer with output compare and input capture, a serial communications port (SIOP), and a computer operating properly (COP) watchdog timer. The HC05 CPU core contains 176 bytes of RAM, 4672 bytes of user EPROM, 239 bytes of bootloader ROM, and 21 input/output (I/O) pins (20 bidirectional, 1 input-only). This device is available in a 28-pin SOIC, PDIP, or windowed DIP package.
产品详情
特征
- 28-Pin SOIC, PDIP, or Windowed DIP Package
- 4672 Bytes of User EPROM (Including 48 Bytes of Page Zero EPROM and 16 Bytes of User Vectors)
- 239 Bytes of Bootloader ROM
- 176 Bytes of On-Chip RAM
- 4-Channel 8-Bit A/D Converter
- SIOP Serial Communications Port
- 16-Bit Timer with Output Compare and Input Capture
- 20 Bidirectional I/O Lines and 1 Input-Only line
- PC0 and PC1 High-Current Outputs
