无线音频和数据流的NFMI无线电

NXH2261UK 正常供应

滚动图片以放大

恩智浦NxH2261是完全集成的单芯片解决方案，采用听力保健行业有着骄人业绩的成熟技术近场磁感应(NFMI)来实现无线音频流和数据通信。

这个超低功耗、单芯片解决方案，采用近场磁感应(NFMI)无线电优化无线音频和数据通信，为用户提供一个强大、紧密包含的体域网。

产品详情

特征

  • 面向无线音频和数据流传输的单芯片解决方案
  • 第二代NFMI技术
    • 低功耗, 稳定耐用, 具有私密性
    • 596 kbit/s传输速率
    • 全球适用
    • 对人体的辐射低
  • 集成式ARM Cortex-M0处理器
    • 广泛的外设系列
    • 用户完全可编程
  • 面向音频处理的CoolFlux DSP
  • 可独立工作或与外部MCU一起工作
  • 灵活的嵌入式网络
    • 最高15个设备
    • 用于低延迟耳到耳通信的优化协议
    • 最多两个音频Tx，两个音频Rx和多个并行数据流
  • 支持的音频采样频率：16 kHz至48 kHz
  • 超低功耗操作
    • 双向音频流：1.2 mA时，采样率为16 kHz
    • 单向音频流：1.95 mA时，采样率为48 kHz
  • 封装为凸起芯片 < 11 mm²
  • 采用单块ZnAir电池来操作
  • 由完整的入门套件提供支持
    • 应用电路板
    • LPCXpresso固件环境
    • 软件开发套件
  • 高效、强大和私密性
  • 人体兼容型
  • 用户可编程
  • 灵活的嵌入式网络
  • 允许高集成度
  • 超低功耗操作
