AFSC5G26E39 2496-2690 MHz, 30 dB, 8 W Avg Data Sheet[AFSC5G26E39]
紧凑列表
2496-2690 MHz, 30 dB, 8 W Avg. Airfast® Power Amplifier Module
The AFSC5G26E39 is a fully integrated Doherty power amplifier module designed for wireless infrastructure applications that demand high performance in the smallest footprint. Ideal for applications in massive MIMO systems, outdoor small cells and low-power remote radio heads. The field-proven LDMOS power amplifiers are designed for TDD and FDD LTE systems.
10 mm x 6 mm Module
产品详情
Features
- Frequency: 2496–2690 MHz
- Advanced high performance in-package Doherty
- Fully matched (50 ohm input/output, DC blocked)
- Designed for low complexity analog or digital linearization systems
- RoHs compliant
RF Performance Table
2496–2690 MHz
Typical LTE Performance: Pout = 8 W Avg., VDD = 27 Vdc, 1 x 20 MHz LTE, Input Signal PAR = 8 dB @ 0.01% Probability on CCDF. (1)| Carrier Center Frequency |
Gain (dB) |
ACPR (dBc) |
PAE (%) |
| 2506 MHz | 29.2 | –26.5 | 40.4 |
| 2600 MHz | 29.6 | –28.0 | 41.8 |
| 2680 MHz | 30.2 | –26.4 | 41.5 |
购买/参数
2 结果
包含 0 不推荐用于新设计
部件 | 订购 | 计算机辅助设计模型 | 状态 | Frequency (Min) (MHz) | Frequency (Max) (MHz) | Supply Voltage (Typ) (V) | Peak Power (Typ) (dBm) | Peak Power (Typ) (W) | 模具技术 |
|---|---|---|---|---|---|---|---|---|---|
正常供应 | 2496 | 2690 | 27 | 47.1 | 51.3 | LDMOS | |||
正常供应 | — | — | — | — | — | — |
