Kinetis® Design Studio集成开发环境(IDE)

KDS_IDE
Kinetis® Design Studio IDE

点击播放视频

Kinetis® Design Studio (KDS)是一种附送的Kinetis MCU集成开发环境，为您的设计提供强大的编辑、编译和调试功能。Kinetis Design Studio IDE基于包括Eclipse、GNU编译器套装(GCC)、GNU调试器(GDB)等免费开源软件，为设计人员提供了一种不限制代码大小的简单开发工具。此外，Processor Expert®软件支持您利用其知识库进行设计，只需几次鼠标点击即可创建强大的应用。

可通过Kinetis软件开发套件(SDK)安装额外的和新的器件支持。

框图

Embedded SW for SIGFOX based on OL2385

Embedded SW for SIGFOX based on OL2385
获取框图PDF

特征

  • Eclipse Luna 4.4
  • 主机操作系统：
    • Windows® 7/8/10 (32位和64位)
    • Linux® 64位(Ubuntu 10.04 (deb)，RedHat/Centos 7 (rpm))
    • Mac OS X (10.10和10.11) ，支持SEGGER J-Link
  • GDB调试器，支持以下调试接口硬件：
    • SEGGER J-Link (配合SEGGER GDB服务器，Windows，Linux，Mac)
    • P&E Multilink (配合P&E GDB服务器，Windows，Linux)
    • CMSIS-DAP (配合OpenOCD GDB和OpenSDA嵌入式电路，Windows，Linux)
    • 采用GDB和OpenOCD TCL的命令行(CL)调试
  • 支持其他可下载Eclipse插件，包括实时操作系统感知(含MQX™和FreeRTOS)
  • 用于创建裸机、Kinetis® SDK v1.x和v2和Processor Expert®软件项目的项目向导
  • Processor Expert软件，支持Kinetis SDK v1.x
  • 支持的语言：汇编语言、C和C++ (均无代码大小限制)
  • 包含的库：launchpad newlib和newlib-nano
  • Kinetis SDK外设驱动和CMSIS兼容启动代码
  • GNU Arm® Eclipse插件，用于托管的Make项目
  • Make文件项目
  • 面向Arm嵌入式处理器的GNU工具 (launchpad)工具链和库
  • 集成式Eclipse CMSIS-SVD Register和Peripheral Viewer
  • 支持MQX项目创建和MQX内核感知(作为MQX下载提供)
  • 支持来自Eclipse生态合作体系或恩智浦网络社区支持合作伙伴的任何Eclipse插件
  • 通过Kinetis SDK提供的Eclipse更新版可以添加额外的器件支持

支持的器件

下载

快速参考恩智浦 软件类型.
筛选条件

1 下载

  • 开发IDE和生成工具

    Design Studio Integrated Development Environment (IDE)

    FLEXERA版本 AllJan 27, 2022 12:54:001 KBKINETIS-KDS-IDE
    下载

注意: 推荐在电脑端下载软件，体验更佳。

Y true 0 SSPKDS_IDEzh 14 参考手册 Reference Manual t877 2 发行说明 Release Note t933 5 快速参考指南 Quick Reference Guide t525 1 数据手册 Data Sheet t520 1 用户指南 User Guide t792 4 简介 Fact Sheet t523 1 zh 4 1 1.0 English Welcome to the Kinetis Design Studio software development tools, a GNU/Eclipse-based development environment for Kinetis devices. 1406836628325719563794 SSP 2.3 MB None None documents None 1406836628325719563794 /docs/en/user-guide/KDSUG.pdf 2264803 /docs/en/user-guide/KDSUG.pdf KDSUG N N 2016-10-31 Kinetis Design Studio V3.0.0 User Guide /docs/en/user-guide/KDSUG.pdf /docs/en/user-guide/KDSUG.pdf User Guide N Y 132339537837198660 2023-06-19 pdf N en Apr 23, 2015 User Guide t792 用户指南 User Guide Y N Kinetis Design Studio V3.0.0 User Guide 2 2 English The Kinetis Design Studio is a complimentary integrated development environment for Kinetis MCUs that enables robust editing, compiling and debugging of your designs. Based on free, open-source software including Eclipse, GNU Compiler Collection (GCC), GNU Debugger (GDB), and others, the Kinetis Design Studio offers designers a straightforward development tool with no code-size limitations. Processor Expert saves time and effort with its knowledge base helping start application development with a few mouse 1396044690393699959701 SSP 452.6 KB None None documents None 1396044690393699959701 /docs/en/fact-sheet/KINDESTDSOFS.pdf 452578 /docs/en/fact-sheet/KINDESTDSOFS.pdf KINDESTDSOFS documents N N 2014-04-07 Kinetis<sup>&#174;</sup> Design Studio IDE Fact Sheet /docs/en/fact-sheet/KINDESTDSOFS.pdf /docs/en/fact-sheet/KINDESTDSOFS.pdf /docs/en/fact-sheet/KINDESTDSOFS.pdf Fact Sheet N Y 736675474163315314 2022-12-07 pdf N en Jun 30, 2015 736675474163315314 Fact Sheet Y N Kinetis<sup>&#174;</sup> Design Studio IDE Fact Sheet 1 Chinese 1396044690393699959701zh SSP 452.6 KB None None documents None 1396044690393699959701 /docs/zh/fact-sheet/KINDESTDSOFS.pdf 452578 /docs/zh/fact-sheet/KINDESTDSOFS.pdf KINDESTDSOFS N N 2014-04-07 Kinetis<sup>&#174;</sup> Design Studio IDE Fact Sheet /docs/zh/fact-sheet/KINDESTDSOFS.pdf /docs/zh/fact-sheet/KINDESTDSOFS.pdf Fact Sheet N Y 736675474163315314 2022-12-07 N zh Fact Sheet t523 简介 Fact Sheet N Kinetis Design Studio IDE简介 3 1 English 1430843557307724482885 SSP 670.2 KB None None documents None 1430843557307724482885 /docs/en/release-note/KDS300RN.pdf 670176 /docs/en/release-note/KDS300RN.pdf KDS300RN N N 2015-05-05 Kinetis<sup>&#174;</sup> Design Studio V3.0.0 Release Notes /docs/en/release-note/KDS300RN.pdf /docs/en/release-note/KDS300RN.pdf Release Note N Y 487216834315582133 2022-12-07 pdf N en May 5, 2015 Release Note t933 发行说明 Release Note Y N Kinetis<sup>&#174;</sup> Design Studio V3.0.0 Release Notes 4 1.0.0 English 1429506235597703356875 SSP 487.3 KB None None documents None 1429506235597703356875 /docs/en/quick-reference-guide/KDSPGQS.pdf 487316 /docs/en/quick-reference-guide/KDSPGQS.pdf KDSPGQS N N 2015-04-24 Kinetis<sup>&#174;</sup> Design Studio v3.0.0 Porting Guide /docs/en/quick-reference-guide/KDSPGQS.pdf /docs/en/quick-reference-guide/KDSPGQS.pdf Quick Reference Guide N Y 803735842453594974 2022-12-07 pdf N en Apr 24, 2015 Quick Reference Guide t525 快速参考指南 Quick Reference Guide Y N Kinetis<sup>&#174;</sup> Design Studio v3.0.0 Porting Guide false zh zh 数据手册 Data Sheet 1 5 MKE14F256VLH16,MKE14F256VLL16,MKE14F512VLH16,MKE14F512VLL16,MKE16F256VLH16,MKE16F256VLL16,MKE16F512VLH16,MKE16F512VLL16,MKE18F256VLH16,MKE18F256VLL16,MKE18F512VLH16,MKE18F512VLL16 4.1 English The KE1xF microcontroller is built on the Arm<sub>&reg;</sub> Cortex<sub>&reg;</sub>-M4 processor with stronger performance and higher memory densities in multiple packages. 1473746642357721985621 SSP 1.7 MB None None documents None 1473746642357721985621 /docs/en/data-sheet/KE1xFP100M168SF0.pdf 1737875 /docs/en/data-sheet/KE1xFP100M168SF0.pdf KE1XFP100M168SF0 documents N N 2016-11-09 Kinetis KE1xF with up to 512 KB Flash /docs/en/data-sheet/KE1xFP100M168SF0.pdf /docs/en/data-sheet/KE1xFP100M168SF0.pdf Data Sheet N 980000996212993340 2023-08-23 en Jan 24, 2022 980000996212993340 Data Sheet Y N Kinetis KE1xF with up to 512 KB Flash 2 Chinese The KE1xF microcontroller is built on the ARM&#174; Cortex&#174;-M4 processor with stronger performance and higher memory densities in multiple packages. 1473746642357721985621zh SSP 1.7 MB None None documents None 1473746642357721985621 /docs/zh/data-sheet/KE1xFP100M168SF0.pdf 1737875 /docs/zh/data-sheet/KE1xFP100M168SF0.pdf KE1XFP100M168SF0 documents N N 2016-11-09 Kinetis KE1xF with up to 512 KB Flash /docs/zh/data-sheet/KE1xFP100M168SF0.pdf /docs/zh/data-sheet/KE1xFP100M168SF0.pdf Data Sheet N 980000996212993340 2023-08-23 pdf N zh 980000996212993340 Data Sheet N Kinetis KE1xF with up to 512 KB Flash 参考手册 Reference Manual 2 6 4 English This reference manual is intended for system software and hardware developers and&#13;&#10;applications programmers who want to develop products with Kinetis KE1xF Sub-Family. 1474079869972699741070 SSP 12.9 MB None None documents None 1474079869972699741070 /docs/en/reference-manual/KE1xFP100M168SF0RM.pdf 12893231 /docs/en/reference-manual/KE1xFP100M168SF0RM.pdf KE1XFP100M168SF0RM documents N N 2016-11-09 Kinetis KE1xF Sub-Family Reference Manual /docs/en/reference-manual/KE1xFP100M168SF0RM.pdf /docs/en/reference-manual/KE1xFP100M168SF0RM.pdf Reference Manual N 500633505221135046 2022-12-07 pdf N en Jun 28, 2019 500633505221135046 Reference Manual Y N Kinetis KE1xF Sub-Family Reference Manual 7 3 English This reference manual is intended for system software and hardware developers and&#13;&#10;applications programmers who want to develop products with Kinetis KE1xZ Sub-Family. 1474023198291723979828 SSP 12.2 MB Registration without Disclaimer None documents Extended 1474023198291723979828 /secured/assets/documents/en/reference-manual/KE1xZP100M72SF0RM.pdf 12215000 /secured/assets/documents/en/reference-manual/KE1xZP100M72SF0RM.pdf KE1XZP100M72SF0RM documents Y N 2016-11-09 Kinetis KE1xZ Sub-Family Reference Manual /webapp/Download?colCode=KE1XZP100M72SF0RM&lang_cd=zh /secured/assets/documents/en/reference-manual/KE1xZP100M72SF0RM.pdf Reference Manual N 500633505221135046 2022-12-07 pdf Y en Aug 23, 2018 500633505221135046 Reference Manual Y N Kinetis KE1xZ Sub-Family Reference Manual 用户指南 User Guide 3 8 0 English Kinetis Design Studio v2.0.0 Porting - User Guide 1416603229194731515627 SSP 472.8 KB None None documents None 1416603229194731515627 /docs/en/user-guide/KDS200PUG.pdf 472805 /docs/en/user-guide/KDS200PUG.pdf KDS200PUG documents N N 2014-11-21 Kinetis<sup>&#174;</sup> Design Studio v2.0.0 Porting - User Guide /docs/en/user-guide/KDS200PUG.pdf /docs/en/user-guide/KDS200PUG.pdf User Guide N 132339537837198660 2022-12-07 pdf N en Nov 20, 2014 132339537837198660 User Guide Y N Kinetis<sup>&#174;</sup> Design Studio v2.0.0 Porting - User Guide 9 0 English Kinetis Design Studio v2.0.0 User Guide 1416603028538711227311 SSP 1.2 MB None None documents None 1416603028538711227311 /docs/en/user-guide/KDS200UG.pdf 1226374 /docs/en/user-guide/KDS200UG.pdf KDS200UG documents N N 2014-11-21 Kinetis<sup>&#174;</sup> Design Studio v2.0.0 User Guide /docs/en/user-guide/KDS200UG.pdf /docs/en/user-guide/KDS200UG.pdf User Guide N 132339537837198660 2023-06-19 pdf N en Nov 20, 2014 132339537837198660 User Guide Y N Kinetis<sup>&#174;</sup> Design Studio v2.0.0 User Guide 10 0 English The CodeWarrior to Kinetis Design Studio project migration assistant assists in the migration of CodeWarrior projects into a&#13;&#10;form that is configurable by the Kinetis Design Studio IDE. It is necessary to manually alter certain project content to achieve&#13;&#10;a successful build in the Kinetis Design Studio IDE. 1406836632434704320840 SSP 490.6 KB None None documents None 1406836632434704320840 /docs/en/user-guide/KDSPUG.pdf 490550 /docs/en/user-guide/KDSPUG.pdf KDSPUG documents N N 2016-10-31 Kinetis Design Studio v1.1.0 Porting User Guide /docs/en/user-guide/KDSPUG.pdf /docs/en/user-guide/KDSPUG.pdf User Guide N 132339537837198660 2023-06-19 pdf N en Jul 31, 2014 132339537837198660 User Guide Y N Kinetis Design Studio v1.1.0 Porting User Guide 发行说明 Release Note 4 11 3.0.1 English Processor Expert<sup>®</sup> for Kinetis is a rapid application design tool for Kinetis devices. It combines easy-to-use componentbased, application creation with an expert knowledge system. The tool can generate code for IAR Arm C Compiler, Keil Arm C/C++ Compiler or GNU C Compiler. 1439304388359711243709 SSP 971.7 KB None None documents None 1439304388359711243709 /docs/en/release-note/PEx_for_Kinetis_3.0.1_RN.pdf 971654 /docs/en/release-note/PEx_for_Kinetis_3.0.1_RN.pdf PEX-KINETIS_3-0-1_RN documents N N 2016-10-31 Processor Expert for Kinetis 3.0.1 Release Notes /docs/en/release-note/PEx_for_Kinetis_3.0.1_RN.pdf /docs/en/release-note/PEx_for_Kinetis_3.0.1_RN.pdf Release Note N 487216834315582133 2022-12-07 pdf N en Aug 11, 2015 487216834315582133 Release Note Y N Processor Expert for Kinetis 3.0.1 Release Notes 12 0 English Kinetis Design Studio V2.0.0 Release Notes 1416516948556725198981 SSP 127.3 KB None None documents None 1416516948556725198981 /docs/en/release-note/KDS200RN.pdf 127293 /docs/en/release-note/KDS200RN.pdf KDS200RN documents N N 2014-11-21 Kinetis<sup>&#174;</sup> Design Studio V2.0.0 Release Notes /docs/en/release-note/KDS200RN.pdf /docs/en/release-note/KDS200RN.pdf Release Note N 487216834315582133 2022-12-07 pdf N en Nov 20, 2014 487216834315582133 Release Note Y N Kinetis<sup>&#174;</sup> Design Studio V2.0.0 Release Notes 13 1 English This is a bug fixing update of the Processor Expert<sup>&#174;</sup> for KDS 1.1.x.&#13;&#10;This short document describes changes introduced by this update. See more details about Processor Expert for KDS 1.1 in the PEx_KDS_1_1_Release_Notes.pdf document 1409329482537724235882 SSP 350.3 KB None None documents None 1409329482537724235882 /docs/en/release-note/PEX_KDS_1_1_RN.pdf 350340 /docs/en/release-note/PEX_KDS_1_1_RN.pdf PEX_KDS_1_1_RN documents N N 2014-08-29 Processor Expert<sup>&#174;</sup> Software Processor Expert for Kinetis<sup>&#174;</sup> Design Studio 1.1 Update 1 - Release Notes /docs/en/release-note/PEX_KDS_1_1_RN.pdf /docs/en/release-note/PEX_KDS_1_1_RN.pdf Release Note N 487216834315582133 2022-12-07 pdf N en Aug 29, 2014 487216834315582133 Release Note Y N Processor Expert<sup>&#174;</sup> Software Processor Expert for Kinetis<sup>&#174;</sup> Design Studio 1.1 Update 1 - Release Notes 14 1.1.1 English The Kinetis Design Studio IDE is a complimentary integrated development environment for Kinetis MCUs that enables robust editing, compiling and debugging of your designs. 1406847170637716487471 SSP 325.6 KB None None documents None 1406847170637716487471 /docs/en/release-note/KDSRN.pdf 325586 /docs/en/release-note/KDSRN.pdf KDSRN documents N N 2016-10-31 Kinetis Design Studio Release Notes /docs/en/release-note/KDSRN.pdf /docs/en/release-note/KDSRN.pdf Release Note N 487216834315582133 2022-12-07 pdf N en Aug 22, 2014 487216834315582133 Release Note Y N Kinetis Design Studio Release Notes false 0 KDS_IDE downloads zh-Hans true 1 Y SSP 参考手册 2 /docs/en/reference-manual/KE1xFP100M168SF0RM.pdf 2016-11-09 1474079869972699741070 SSP 6 Jun 28, 2019 Reference Manual This reference manual is intended for system software and hardware developers and&#13;&#10;applications programmers who want to develop products with Kinetis KE1xF Sub-Family. None /docs/en/reference-manual/KE1xFP100M168SF0RM.pdf English documents 12893231 None 500633505221135046 2022-12-07 N /docs/en/reference-manual/KE1xFP100M168SF0RM.pdf Kinetis KE1xF Sub-Family Reference Manual /docs/en/reference-manual/KE1xFP100M168SF0RM.pdf documents 500633505221135046 Reference Manual N en None Y pdf 4 N N Kinetis KE1xF Sub-Family Reference Manual 12.9 MB KE1XFP100M168SF0RM N 1474079869972699741070 /secured/assets/documents/en/reference-manual/KE1xZP100M72SF0RM.pdf 2016-11-09 1474023198291723979828 SSP 7 Aug 23, 2018 Reference Manual This reference manual is intended for system software and hardware developers and&#13;&#10;applications programmers who want to develop products with Kinetis KE1xZ Sub-Family. Registration without Disclaimer /secured/assets/documents/en/reference-manual/KE1xZP100M72SF0RM.pdf English documents 12215000 None 500633505221135046 2022-12-07 Y /webapp/Download?colCode=KE1XZP100M72SF0RM&lang_cd=zh Kinetis KE1xZ Sub-Family Reference Manual /secured/assets/documents/en/reference-manual/KE1xZP100M72SF0RM.pdf documents 500633505221135046 Reference Manual N en Extended Y pdf 3 Y N Kinetis KE1xZ Sub-Family Reference Manual 12.2 MB KE1XZP100M72SF0RM N 1474023198291723979828 发行说明 5 /docs/en/release-note/PEx_for_Kinetis_3.0.1_RN.pdf 2016-10-31 1439304388359711243709 SSP 11 Aug 11, 2015 Release Note Processor Expert<sup>®</sup> for Kinetis is a rapid application design tool for Kinetis devices. It combines easy-to-use componentbased, application creation with an expert knowledge system. The tool can generate code for IAR Arm C Compiler, Keil Arm C/C++ Compiler or GNU C Compiler. None /docs/en/release-note/PEx_for_Kinetis_3.0.1_RN.pdf English documents 971654 None 487216834315582133 2022-12-07 N /docs/en/release-note/PEx_for_Kinetis_3.0.1_RN.pdf Processor Expert for Kinetis 3.0.1 Release Notes /docs/en/release-note/PEx_for_Kinetis_3.0.1_RN.pdf documents 487216834315582133 Release Note N en None Y pdf 3.0.1 N N Processor Expert for Kinetis 3.0.1 Release Notes 971.7 KB PEX-KINETIS_3-0-1_RN N 1439304388359711243709 /docs/en/release-note/KDS200RN.pdf 2014-11-21 1416516948556725198981 SSP 12 Nov 20, 2014 Release Note Kinetis Design Studio V2.0.0 Release Notes None /docs/en/release-note/KDS200RN.pdf English documents 127293 None 487216834315582133 2022-12-07 N /docs/en/release-note/KDS200RN.pdf Kinetis<sup>&#174;</sup> Design Studio V2.0.0 Release Notes /docs/en/release-note/KDS200RN.pdf documents 487216834315582133 Release Note N en None Y pdf 0 N N Kinetis<sup>&#174;</sup> Design Studio V2.0.0 Release Notes 127.3 KB KDS200RN N 1416516948556725198981 /docs/en/release-note/PEX_KDS_1_1_RN.pdf 2014-08-29 1409329482537724235882 SSP 13 Aug 29, 2014 Release Note This is a bug fixing update of the Processor Expert<sup>&#174;</sup> for KDS 1.1.x.&#13;&#10;This short document describes changes introduced by this update. See more details about Processor Expert for KDS 1.1 in the PEx_KDS_1_1_Release_Notes.pdf document None /docs/en/release-note/PEX_KDS_1_1_RN.pdf English documents 350340 None 487216834315582133 2022-12-07 N /docs/en/release-note/PEX_KDS_1_1_RN.pdf Processor Expert<sup>&#174;</sup> Software Processor Expert for Kinetis<sup>&#174;</sup> Design Studio 1.1 Update 1 - Release Notes /docs/en/release-note/PEX_KDS_1_1_RN.pdf documents 487216834315582133 Release Note N en None Y pdf 1 N N Processor Expert<sup>&#174;</sup> Software Processor Expert for Kinetis<sup>&#174;</sup> Design Studio 1.1 Update 1 - Release Notes 350.3 KB PEX_KDS_1_1_RN N 1409329482537724235882 /docs/en/release-note/KDSRN.pdf 2016-10-31 1406847170637716487471 SSP 14 Aug 22, 2014 Release Note The Kinetis Design Studio IDE is a complimentary integrated development environment for Kinetis MCUs that enables robust editing, compiling and debugging of your designs. None /docs/en/release-note/KDSRN.pdf English documents 325586 None 487216834315582133 2022-12-07 N /docs/en/release-note/KDSRN.pdf Kinetis Design Studio Release Notes /docs/en/release-note/KDSRN.pdf documents 487216834315582133 Release Note N en None Y pdf 1.1.1 N N Kinetis Design Studio Release Notes 325.6 KB KDSRN N 1406847170637716487471 /docs/en/release-note/KDS300RN.pdf 2015-05-05 1430843557307724482885 SSP 3 May 5, 2015 Release Note 发行说明 None /docs/en/release-note/KDS300RN.pdf English 670176 None Release Note 2022-12-07 N /docs/en/release-note/KDS300RN.pdf Kinetis<sup>&#174;</sup> Design Studio V3.0.0 Release Notes /docs/en/release-note/KDS300RN.pdf documents 487216834315582133 Release Note N Y en None Y t933 pdf 1 N N Kinetis<sup>&#174;</sup> Design Studio V3.0.0 Release Notes 670.2 KB KDS300RN N 1430843557307724482885 快速参考指南 1 /docs/en/quick-reference-guide/KDSPGQS.pdf 2015-04-24 1429506235597703356875 SSP 4 Apr 24, 2015 Quick Reference Guide 快速参考指南 None /docs/en/quick-reference-guide/KDSPGQS.pdf English 487316 None Quick Reference Guide 2022-12-07 N /docs/en/quick-reference-guide/KDSPGQS.pdf Kinetis<sup>&#174;</sup> Design Studio v3.0.0 Porting Guide /docs/en/quick-reference-guide/KDSPGQS.pdf documents 803735842453594974 Quick Reference Guide N Y en None Y t525 pdf 1.0.0 N N Kinetis<sup>&#174;</sup> Design Studio v3.0.0 Porting Guide 487.3 KB KDSPGQS N 1429506235597703356875 数据手册 1 /docs/zh/data-sheet/KE1xFP100M168SF0.pdf 2016-11-09 1473746642357721985621zh SSP 5 Data Sheet The KE1xF microcontroller is built on the ARM&#174; Cortex&#174;-M4 processor with stronger performance and higher memory densities in multiple packages. None /docs/zh/data-sheet/KE1xFP100M168SF0.pdf Chinese documents 1737875 None 980000996212993340 2023-08-23 N /docs/zh/data-sheet/KE1xFP100M168SF0.pdf Kinetis KE1xF with up to 512 KB Flash /docs/zh/data-sheet/KE1xFP100M168SF0.pdf documents 980000996212993340 Data Sheet N zh None pdf 2 N N Kinetis KE1xF with up to 512 KB Flash 1.7 MB KE1XFP100M168SF0 N 1473746642357721985621 用户指南 4 /docs/en/user-guide/KDS200PUG.pdf 2014-11-21 1416603229194731515627 SSP 8 Nov 20, 2014 User Guide Kinetis Design Studio v2.0.0 Porting - User Guide None /docs/en/user-guide/KDS200PUG.pdf English documents 472805 None 132339537837198660 2022-12-07 N /docs/en/user-guide/KDS200PUG.pdf Kinetis<sup>&#174;</sup> Design Studio v2.0.0 Porting - User Guide /docs/en/user-guide/KDS200PUG.pdf documents 132339537837198660 User Guide N en None Y pdf 0 N N Kinetis<sup>&#174;</sup> Design Studio v2.0.0 Porting - User Guide 472.8 KB KDS200PUG N 1416603229194731515627 /docs/en/user-guide/KDS200UG.pdf 2014-11-21 1416603028538711227311 SSP 9 Nov 20, 2014 User Guide Kinetis Design Studio v2.0.0 User Guide None /docs/en/user-guide/KDS200UG.pdf English documents 1226374 None 132339537837198660 2023-06-19 N /docs/en/user-guide/KDS200UG.pdf Kinetis<sup>&#174;</sup> Design Studio v2.0.0 User Guide /docs/en/user-guide/KDS200UG.pdf documents 132339537837198660 User Guide N en None Y pdf 0 N N Kinetis<sup>&#174;</sup> Design Studio v2.0.0 User Guide 1.2 MB KDS200UG N 1416603028538711227311 /docs/en/user-guide/KDSPUG.pdf 2016-10-31 1406836632434704320840 SSP 10 Jul 31, 2014 User Guide The CodeWarrior to Kinetis Design Studio project migration assistant assists in the migration of CodeWarrior projects into a&#13;&#10;form that is configurable by the Kinetis Design Studio IDE. It is necessary to manually alter certain project content to achieve&#13;&#10;a successful build in the Kinetis Design Studio IDE. None /docs/en/user-guide/KDSPUG.pdf English documents 490550 None 132339537837198660 2023-06-19 N /docs/en/user-guide/KDSPUG.pdf Kinetis Design Studio v1.1.0 Porting User Guide /docs/en/user-guide/KDSPUG.pdf documents 132339537837198660 User Guide N en None Y pdf 0 N N Kinetis Design Studio v1.1.0 Porting User Guide 490.6 KB KDSPUG N 1406836632434704320840 /docs/en/user-guide/KDSUG.pdf 2016-10-31 1406836628325719563794 SSP 1 Apr 23, 2015 User Guide 用户指南 Welcome to the Kinetis Design Studio software development tools, a GNU/Eclipse-based development environment for Kinetis devices. None /docs/en/user-guide/KDSUG.pdf English 2264803 None User Guide 2023-06-19 N /docs/en/user-guide/KDSUG.pdf Kinetis Design Studio V3.0.0 User Guide /docs/en/user-guide/KDSUG.pdf documents 132339537837198660 User Guide N Y en None Y t792 pdf 1.0 N N Kinetis Design Studio V3.0.0 User Guide 2.3 MB KDSUG N 1406836628325719563794 简介 1 /docs/zh/fact-sheet/KINDESTDSOFS.pdf 2014-04-07 1396044690393699959701zh SSP 2 Fact Sheet 简介 None /docs/zh/fact-sheet/KINDESTDSOFS.pdf Chinese 452578 None Fact Sheet 2022-12-07 N /docs/zh/fact-sheet/KINDESTDSOFS.pdf Kinetis Design Studio IDE简介 /docs/zh/fact-sheet/KINDESTDSOFS.pdf documents 736675474163315314 Fact Sheet N Y zh None t523 1 N N Kinetis<sup>&#174;</sup> Design Studio IDE Fact Sheet 452.6 KB KINDESTDSOFS N 1396044690393699959701 true Y Softwares

文档

快速参考恩智浦 文档类别.

筛选条件

1-10 / 14 文件

紧凑列表

参考手册 (2)
发行说明 (5)
快速参考指南 (1)
数据手册 (1)
用户指南 (4)
简介 (1)

硬件

快速参考恩智浦 板类型.
筛选条件

1-5 / 7 硬件

展开
