2496-2690 MHz, 26 dBm Avg., 48 V Airfast® RF Power LDMOS Transistor
- 本页面包含有关样品阶段产品的信息。此处的规格和信息如有更改，恕不另行通知。如需了解其他信息，请联系支持人员或您的销售代表。
This A3V26S004N 26 dBm RF power LDMOS transistor is designed for cellular base station applications covering the frequency range of 2496 to 2690 MHz.
产品详情
RF Performance Table
2600 MHz
Typical Single-Carrier W-CDMA Reference Circuit Performance: VDD = 42 Vdc, IDQ = 17 mA, Pout = 23.5 dBm Avg., Input Signal PAR = 9.9 dB @ 0.01% Probability on CCDF.(1)| Frequency | Gps (dB) |
ηD (%) |
Output PAR (dB) |
ACPR (dBc) |
| 2515 MHz | 23.2 | 15.1 | 10.3 | -35.0 |
| 2595 MHz | 23.0 | 15.5 | 9.6 | -37.0 |
| 2675 MHz | 22.0 | 14.8 | 9.3 | -37.7 |
