MIFARE Ultralight AES：增强了限定使用的免接触式应用的安全性

MF0AESx20
正常供应

滚动图片以放大

MIFARE Ultralight AES IC支持AES加密身份验证，为限定使用的票据和密钥卡提供了更高级别的信任。该IC是传统纸质票、磁条、条形码和二维码系统的免接触式安全替代品，为解决方案提供商提供了一种更安全的便捷方式来发行单程和多用途交通票、活动票、通行证和积分卡。此外，在酒店应用方面，它让来宾可以安全地进入酒店房间和其他酒店设施，包括水疗中心、健身房和停车场。

安全性：

  • 基于AES身份验证可保护数据访问，提供128位密钥长度和可选命令计数器，以限制身份验证失败尝试次数
  • 面向消息完整性保护的CMAC保护
  • 可选的AES认证保护，可保护3个24位单向计数器中的1个计数器
  • EAL 3+通用标准认证

产品详情

特性

隐私和所有权

  • 提供7字节UID，支持可选的随机ID以增强隐私。
  • 基于ECC的独创性签名（预设）
  • 利用AES认证基于128位原始密钥的独创性检查

免接触式性能

  • 符合ISO/IEC14443 A第2/3部分标准
  • 工作距离：远至10cm
  • 数据传输速率：106kbit/s

存储器

  • 144字节EEPROM用户存储器
  • 单次写操作次数：100000次

可扩展性

  • 使用与前代MIFARE Ultralight产品相同的内存结构，可轻松设计
  • 使用相同的AES身份验证命令，有助于简化集成，并支持MIFARE IC系列内的可扩展性

购买/参数

6 结果

包含 0 不推荐用于新设计

部件

展开描述

订购

计算机辅助设计模型

状态

特性

安全

MF0AES2000DA8
数据手册

正常供应

128-bit AES authentication, CMAC for message integrity protection, Originality Signature, Random ID

CC EAL3+

MF0AES2001DUD
数据手册

正常供应

128-bit AES authentication, CMAC for message integrity protection, Originality Signature, Random ID

CC EAL3+

MF0AES2001DUF
数据手册

正常供应

128-bit AES authentication, CMAC for message integrity protection, Originality Signature, Random ID

CC EAL3+

MF0AESH2000DA8
数据手册

正常供应

128-bit AES authentication, CMAC for message integrity protection, Originality Signature, Random ID

CC EAL3+

MF0AESH2001DUD
数据手册

正常供应

128-bit AES authentication, CMAC for message integrity protection, Originality Signature, Random ID

CC EAL3+

MF0AESH2001DUF
数据手册

正常供应

128-bit AES authentication, CMAC for message integrity protection, Originality Signature, Random ID

CC EAL3+

N true 0 PSPMF0AESx20zh 7 封装信息 Package Information t790 1 应用笔记 Application Note t789 3 支持信息 Supporting Information t531 1 数据手册 Data Sheet t520 1 简介 Fact Sheet t523 1 zh zh zh 数据手册 Data Sheet 1 1 3.2 English With cryptographic authentication that’s easy to integrate into existing infrastructures, the MIFARE Ultralight AES IC adds security, privacy, and scalability to a variety of limited-use contactless applications. 1645201539040724256219 PSP 664.5 KB None None documents 1645201539040724256219 /docs/en/data-sheet/MF0AES(H)20.pdf 664458 /docs/en/data-sheet/MF0AES(H)20.pdf MF0AES(H)20 documents N N 2022-02-18 MIFARE Ultralight AES Contactless Limited-Use IC /docs/en/data-sheet/MF0AES(H)20.pdf /docs/en/data-sheet/MF0AES(H)20.pdf Data Sheet N 980000996212993340 2023-07-24 pdf N en Mar 28, 2023 980000996212993340 Data Sheet Y N MIFARE Ultralight AES Contactless Limited-Use IC 应用笔记 Application Note 3 2 1.2 English This document provides guidance for engineers designing loop antenna coils for MIFARE Ultralight AES. 1645287817949692197633 PSP 542.0 KB None None documents None 1645287817949692197633 /docs/en/application-note/AN13453.pdf 541979 /docs/en/application-note/AN13453.pdf AN13453 documents N N 2022-02-19 Card Coil Design Notes for MIFARE Ultralight AES /docs/en/application-note/AN13453.pdf /docs/en/application-note/AN13453.pdf Application Note N 645036621402383989 2022-12-07 pdf N en Apr 20, 2022 645036621402383989 Application Note Y N Card Coil Design Notes for MIFARE Ultralight AES 3 1.1 English This document gives a quick introduction to MIFARE Ultralight AES and lists all supporting documents, software tools and further material that is available and offered from NXP for an easy product design-in. It summarizes all information required for somebody who wants to start solution development including MIFARE Ultralight AES. 1645288037299717446087 PSP 176.9 KB None None documents None 1645288037299717446087 /docs/en/application-note/AN13454.pdf 176905 /docs/en/application-note/AN13454.pdf AN13454 documents N N 2022-02-19 MIFARE Ultralight AES – Quick Start Guide /docs/en/application-note/AN13454.pdf /docs/en/application-note/AN13454.pdf Application Note N 645036621402383989 2022-12-07 pdf N en Feb 19, 2022 645036621402383989 Application Note Y N MIFARE Ultralight AES – Quick Start Guide 4 1.1 English This document presents features and hints for a secured and optimized application development using MIFARE Ultralight AES cards. 1645200867632720836501 PSP 319.0 KB None None documents None 1645200867632720836501 /docs/en/application-note/AN13452.pdf 319005 /docs/en/application-note/AN13452.pdf AN13452 documents N N 2022-02-18 MIFARE Ultralight AES - Features and Hints /docs/en/application-note/AN13452.pdf /docs/en/application-note/AN13452.pdf Application Note N 645036621402383989 2022-12-07 pdf N en Feb 18, 2022 645036621402383989 Application Note Y N MIFARE Ultralight AES - Features and Hints 简介 Fact Sheet 1 5 0 English With cryptographic authentication that’s easy to integrate into existing infrastructures, the MIFARE Ultralight AES IC adds security, privacy, and scalability to a variety of limited-use contactless applications. 1644607562007706494250 PSP 197.6 KB None None documents None 1644607562007706494250 /docs/en/fact-sheet/MIFAREULAESFSA4.pdf 197636 /docs/en/fact-sheet/MIFAREULAESFSA4.pdf MIFAREULAESFSA4 documents N N 2022-02-11 Enhanced Security for Limited-Use Contactless Applications /docs/en/fact-sheet/MIFAREULAESFSA4.pdf /docs/en/fact-sheet/MIFAREULAESFSA4.pdf Fact Sheet N 736675474163315314 2022-12-07 pdf N en Feb 11, 2022 736675474163315314 Fact Sheet Y N Enhanced Security for Limited-Use Contactless Applications 封装信息 Package Information 1 6 1.0 English 1455078601357720544153 PSP 224.8 KB None None documents None 1455078601357720544153 /docs/en/package-information/SOT500-4.pdf 224805 /docs/en/package-information/SOT500-4.pdf SOT500-4 documents N N 2016-02-12 plastic leadless module carrier package; 35 mm wide tape /docs/en/package-information/SOT500-4.pdf /docs/en/package-information/SOT500-4.pdf Package Information N 302435339416912908 2023-06-18 pdf N en Feb 8, 2016 302435339416912908 Package Information Y N plastic leadless module carrier package; 35 mm wide tape 支持信息 Supporting Information 1 7 5.2 English 1715277318022727895773 PSP 532.5 KB None None documents None 1715277318022727895773 /docs/en/supporting-information/MIFARE-Trademark-and-Branding-Guidelines.pdf 532503 /docs/en/supporting-information/MIFARE-Trademark-and-Branding-Guidelines.pdf MFTMKBRNDG documents N N 2024-05-09 MIFARE Trademark Usage Guidelines /docs/en/supporting-information/MIFARE-Trademark-and-Branding-Guidelines.pdf /docs/en/supporting-information/MIFARE-Trademark-and-Branding-Guidelines.pdf Supporting Information N 371282830530968666 2025-03-19 pdf N en Mar 10, 2025 updated 371282830530968666 Supporting Information Y N MIFARE Trademark Usage Guidelines false 0 MF0AESx20 downloads zh-Hans true 1 Y PSP Y Y 封装信息 1 /docs/en/package-information/SOT500-4.pdf 2016-02-12 1455078601357720544153 PSP 6 Feb 8, 2016 Package Information None /docs/en/package-information/SOT500-4.pdf English documents 224805 None 302435339416912908 2023-06-18 N /docs/en/package-information/SOT500-4.pdf plastic leadless module carrier package; 35 mm wide tape /docs/en/package-information/SOT500-4.pdf documents 302435339416912908 Package Information N en None Y pdf 1.0 N N plastic leadless module carrier package; 35 mm wide tape 224.8 KB SOT500-4 N 1455078601357720544153 应用笔记 3 /docs/en/application-note/AN13453.pdf 2022-02-19 1645287817949692197633 PSP 2 Apr 20, 2022 Application Note This document provides guidance for engineers designing loop antenna coils for MIFARE Ultralight AES. None /docs/en/application-note/AN13453.pdf English documents 541979 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN13453.pdf Card Coil Design Notes for MIFARE Ultralight AES /docs/en/application-note/AN13453.pdf documents 645036621402383989 Application Note N en None Y pdf 1.2 N N Card Coil Design Notes for MIFARE Ultralight AES 542.0 KB AN13453 N 1645287817949692197633 /docs/en/application-note/AN13454.pdf 2022-02-19 1645288037299717446087 PSP 3 Feb 19, 2022 Application Note This document gives a quick introduction to MIFARE Ultralight AES and lists all supporting documents, software tools and further material that is available and offered from NXP for an easy product design-in. It summarizes all information required for somebody who wants to start solution development including MIFARE Ultralight AES. None /docs/en/application-note/AN13454.pdf English documents 176905 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN13454.pdf MIFARE Ultralight AES – Quick Start Guide /docs/en/application-note/AN13454.pdf documents 645036621402383989 Application Note N en None Y pdf 1.1 N N MIFARE Ultralight AES – Quick Start Guide 176.9 KB AN13454 N 1645288037299717446087 /docs/en/application-note/AN13452.pdf 2022-02-18 1645200867632720836501 PSP 4 Feb 18, 2022 Application Note This document presents features and hints for a secured and optimized application development using MIFARE Ultralight AES cards. None /docs/en/application-note/AN13452.pdf English documents 319005 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN13452.pdf MIFARE Ultralight AES - Features and Hints /docs/en/application-note/AN13452.pdf documents 645036621402383989 Application Note N en None Y pdf 1.1 N N MIFARE Ultralight AES - Features and Hints 319.0 KB AN13452 N 1645200867632720836501 支持信息 1 /docs/en/supporting-information/MIFARE-Trademark-and-Branding-Guidelines.pdf 2024-05-09 1715277318022727895773 PSP 7 Mar 10, 2025 Supporting Information None /docs/en/supporting-information/MIFARE-Trademark-and-Branding-Guidelines.pdf English documents 532503 None 371282830530968666 2025-03-19 N /docs/en/supporting-information/MIFARE-Trademark-and-Branding-Guidelines.pdf MIFARE Trademark Usage Guidelines /docs/en/supporting-information/MIFARE-Trademark-and-Branding-Guidelines.pdf documents 371282830530968666 Supporting Information N updated en None Y pdf 5.2 N N MIFARE Trademark Usage Guidelines 532.5 KB MFTMKBRNDG N 1715277318022727895773 数据手册 1 /docs/en/data-sheet/MF0AES(H)20.pdf 2022-02-18 1645201539040724256219 PSP 1 Mar 28, 2023 Data Sheet With cryptographic authentication that’s easy to integrate into existing infrastructures, the MIFARE Ultralight AES IC adds security, privacy, and scalability to a variety of limited-use contactless applications. None /docs/en/data-sheet/MF0AES(H)20.pdf English documents 664458 None 980000996212993340 2023-07-24 N /docs/en/data-sheet/MF0AES(H)20.pdf MIFARE Ultralight AES Contactless Limited-Use IC /docs/en/data-sheet/MF0AES(H)20.pdf documents 980000996212993340 Data Sheet N en Y pdf 3.2 N N MIFARE Ultralight AES Contactless Limited-Use IC 664.5 KB MF0AES(H)20 N 1645201539040724256219 简介 1 /docs/en/fact-sheet/MIFAREULAESFSA4.pdf 2022-02-11 1644607562007706494250 PSP 5 Feb 11, 2022 Fact Sheet With cryptographic authentication that’s easy to integrate into existing infrastructures, the MIFARE Ultralight AES IC adds security, privacy, and scalability to a variety of limited-use contactless applications. None /docs/en/fact-sheet/MIFAREULAESFSA4.pdf English documents 197636 None 736675474163315314 2022-12-07 N /docs/en/fact-sheet/MIFAREULAESFSA4.pdf Enhanced Security for Limited-Use Contactless Applications /docs/en/fact-sheet/MIFAREULAESFSA4.pdf documents 736675474163315314 Fact Sheet N en None Y pdf 0 N N Enhanced Security for Limited-Use Contactless Applications 197.6 KB MIFAREULAESFSA4 N 1644607562007706494250 true Y Products
