OM13516UL：PCF85263B评估板

OM13516UL
正常供应
  • 本页面包含有关样品阶段产品的信息。此处的规格和信息如有更改，恕不另行通知。如需了解其他信息，请联系支持人员或您的销售代表。

滚动图片以放大

OM13516UL是PCF85263B的评估板。恩智浦 PCF85263是一款CMOS实时时钟(RTC)和日历，适用于低功耗应用，并在市电电源受损时自动切换到电池。PCF85263可配置为秒表(或已用时间计数器)，分辨率最高可达1/100秒。三次时间戳可以轻松注册特殊事件，该器件还可以注册篡改检测或电池切换时间。

产品详情

特征

多种工作模式

  • 时钟(秒到99年)
  • 秒表或已用时间计数器 (1/100秒至999 999小时)
  • 并行看门狗

电源管理

  • 电池输入电压可低于或高于VDD

通用特性

  • 符合UL要求
  • Time-stamp input, three timestamp registers
  • 两个独立的报警器
  • 通过命令进行电子频率调谐
  • 宽时钟工作电压范围(0.9至5.5 V)
  • 非常适合电池供电的操作(IDD= ~0.27 μA)
  • 400 kHz双线路I2C总线接口(VDD = 1.8至5.5 V)
  • E15SO8、TSSOP8、TSSOP10和小型DFN2626封装

购买选项

OM13516-Image

点击展开

  • OM13516
    正常供应

  • PCF85263B Evaluation board.
