i.MX RT1180：带TSN交换机和EdgeLock®的跨界MCU

i.MX-RT1180
试生产
  • 本页介绍的产品处于样品阶段。此处的产品技术规格和信息如有变更，恕不另行通知。如需了解更多信息和样品供货情况，请联系恩智浦 支持服务或恩智浦当地销售人员。
带TSN开关的多协议i.MX RT1180 MCU

点击播放视频

i.MX RT1180跨界MCU是双核实时微控制器（MCU），采用Arm®Cortex®-M7和Arm®Cortex®M33内核，实现高性能和实时控制功能。i.MX RT1180集成了千兆时间敏感网络（TSN）交换机和EtherCAT从机控制器，非常适合工业和汽车通信应用。

i.MX RT1180 CM7的运行频率高达800MHz，CM33的运行频率高达240MHz，片上RAM为1.5MB。该系列支持多种协议，实现了实时以太网和工业4.0系统之间的通信桥接。i.MX RT1180还提供先进的信息安全，集成了EdgeLock®安全区域。

i.MX RT1180系列由MCUXpresso生态合作体系支持，其中包括SDK、IDE选项以及安全配置和配置工具，可实现快速开发。

框图

i.MX RT1180跨界MCU

i.MX RT1180 Crossover MCU
获取框图PDF

特性

多核处理

  • 800MHz的Arm Cortex-M7+240MHz的Arm Cortex-M33
    • 可选：单核Arm Cortex-M33

软件和工具

  • MCUXpresso生态合作体系支持
    • IDE选项的选择
    • 引脚、时钟、外设、安全和存储器配置工具
    • 安全编程和配置工具
    • 软件开发套件（SDK）
  • 支持Zephyr实时操作系统（RTOS）

网络

  • 恩智浦首款带有千兆（Gbps）时间敏感网络（TSN）交换机的实时微控制器支持多种协议，可在现有系统和Industry 4.0之间桥接通信。
    • 实时工业以太网协议，如Profinet、以太网/IP、EtherCAT、CC-Link IE Field、HSR等。
    • 符合工业自动化IEC60802的最新一代TSN标准
    • 基于TSN的协议，如OPC UA Pub Sub、Profinet over TSN和CC Link IE TSN
  • 高达5Gbps的端口，包括TSN交换机（第2层）上的4个端口和TSN端点控制器上的1个端口
  • L2管理状态，具有先进的流量控制功能，包括端口计数器，过滤器等

先进的信息安全

  • 恩智浦首款集成EdgeLock®安全区域的跨界MCU
    • 预配置、自管理式自主安全子系统，降低了针对联网工业物联网应用的系统级稳健安全部署的复杂性
  • 为IEC62443系统合规性提供组件级基础
  • 在具有安全启动、安全密钥机制和高性能加密的复杂网络系统中，满足信任根要求
  • 使用安全RTC和10个篡改引脚支持系统级物理篡改监控

片上存储器

  • 高达1.5MB的SRAM（受ECC保护），带有面向Arm Cortex-M7的512KB TCM和面向Arm Cortex-M33的256KB TCM

模拟

  • 高速16位模数转换器
  • 先进的定时器/PWM和delta sigma解调器

温度和认证

  • 强大的扩展工业工作温度范围（-40°C至125°C）
  • 汽车AEC-Q100认证（可选）

封装

  • 289 MAPBGA, 14x14mm, 0.8mm间距
  • 144 MAPBGA, 10x10mm, 0.8mm间距
