带有高性能NFC读卡器、可定制MCU和安全工具箱的单芯片解决方案

PN7642
正常供应
PN7642：NFC读卡器、MCU与单芯片安全

点击播放视频

PN7642是一款高度集成的可定制解决方案，结合了高性能NFC读卡器、基于Arm® Cortex®-M33的低功耗MCU和180kB可编程闪存，以及针对安全密钥存储和加密进行优化的SESIP认证安全系统。

PN7642是一款通用的解决方案，可取代对额外MCU和专用安全芯片的需求。一套控制器和主机接口，外加全面的产品支持包，支持快速设计。

框图

PN7642

PN7642
获取框图PDF

特性

  • Arm CortexM-33内核：90MHz、20kB用户RAM、180kB用户闪存。
  • 支持读/写和卡仿真模式、符合NFC Forum的NFC读卡器。
    • R/W模式：ISO/IEC14443A-B和传统B'、FeliCa™、ISO15693、ISO18000 EPC-HF。完整的MIFARE®、DESFire®、NTAG®（NTAG 5到212kbit/s）、ICODE®和SmartMX®系列
    • CE模式：具有ALM/PLM的ISO/IEC14443-4A，最高可达848kbps
  • 高输出功率2W：最大工作发射机电流350MA，具有动态功率控制（DPC2.0）和自动波形控制（AWC）
  • 集成DC/DC支持带最大发射功率的单路3.3V电源
  • 超低功耗卡检测（22µA型）
  • 支持ECP2.0（Apple增强型免接触式轮询）
    • 对称和非对称算法的硬件加速
    • 最多可存储13个128位对称密钥（或6个256位密钥）的安全密钥库
    • 防止旁路攻击的软件保护
  • 2.4至5.5V的电源
  • 丰富的接口
    • SPI（高达15Mbit/s）和I²C（高达3.4Mbit/s）控制器
    • I²C、I³C（高达3.4Mbit/s）和SPI目标
    • 高达21个通用IO
    • USB设备和HSUART
    • 3个PWM接口，ADC（10位）（无DPC配置）
    • 连接TDA的ISO-AUX接口
    • 4个GP 32位定时器，1个WD定时器，SWD接口
  • 广泛的支持工具，包括集成到MCUXpressoIDE/SDK
  • 从主机接口、NFC和用户应用更新固件
  • 扩展工作温度范围：-40到+105°C
  • GlobalPlatform认证的SESIP L2
  • VFBGA64封装（4.5x4.5x0.8mm）
  • 由NFC Cockpit配置工具提供支持

购买/参数

1 结果

包含 0 不推荐用于新设计

部件

展开描述

订购

计算机辅助设计模型

状态

Read distance [TYP] (mm)

Free Programmable CPU

特点

Contactless Identification Standard

内核类型

Host Interface

Controller Interface

Host interface protocol

输入电压[最小到最大]（V）

RF driver supply voltage [min-max] (V)

RF driver current [max](mA)

Max output power (W)

User Non volatile memory size [kB]

RAM (kB)

Ambient Operating Temperature (Min to Max) (℃)

Package Dimensions (LxWxZ (mm))

封装类型

封装端接数

PN7642EV
数据手册

正常供应

200

Arm Cortex-M33

NFC reader/writer, card emulation

FeliCa, ISO/IEC 14443 Type A, ISO/IEC 14443 Type B, ISO/IEC 15693, ISO/IEC 18092

Arm Cortex-M33

I2C, SPI, UART, USB

I²C, UART

CCID, register level command- response

1.8 to 3.5

2.4 - 6

350

2

180

32

-40 to 105

4.5 x 4.5 x 0.8

VFBGA64

64
